Product Details

Place of Origin	Zhejiang, China	Brand Name	SANRONG
Type	Other, Oil separator	Application	Refrigeration Parts
Certification	Other, RoHS

Product Description

Specifications

Sanrong oil separator selling to Dunhum-Bush,Haier,Midea and so on

Refrigerant: R22/R134a/R404A/R407C/R502/R507
Medium temperature: -40 to +120
Max working Pressure:3100Kpa.
Destructive testing reached 17.5 to 19Mpa.
The thickness of paint film: 50 to 80 micron.
Oil Storage Capacity: 55824-559011/ 5201-5205 600ml
569011-569417 /6203-6205 800ml

TYPE	ODF Connections only(in)		SAE Oil Connection(SAE Flare)	Dimensions
TYPE	in	mm	SAE Oil Connection(SAE Flare)	A(in)	B(in)
SRW-5201	1/2	12.8	1/4" or 3/8"	4.00	10.75
SRW-5202	5/8	16.0	1/4" or 3/8"	4.00	14.25
SRW-5203	7/8	22.4	1/4" or 3/8"	4.00	17.75
SRW-5204	1-1/8	28.8	1/4" or 3/8"	4.00	21.00
SRW-5205	1-3/8	35.0	1/4" or 3/8"	4.00	21.25
SRW-6203	1-3/8	35.0	1/4" or 3/8"	6.00	15.75
SRW-6204	1-5/8	42.0	1/4" or 3/8"	6.00	19.00
SRW-6205	2-1/8	54.0	1/4" or 3/8"	6.00	19.95

SRW-606----SRW-609 Dimension
TYPE	Max.Working Pressure (MPa)	Connections(in)	SAEOil Connection(SAE Flare)	Diameter(in)	L1(in)	L2(in)	Oil Charge Amount
TYPE	Max.Working Pressure (MPa)	Connections(in)	SAEOil Connection(SAE Flare)	Diameter(in)	L1(in)	L2(in)	OZ	ml
SRW-606	4.5	1-5/8"ODF	3/8"	6"	13-1/2	18-3/8	29	850
SRW-607	4.5	2-1/8"ODF	3/8"	6"	14-1/2	19-3/8	29	850
SRW-608	4.5	2-5/8"ODF	3/8"	6"	14-1/2	19-3/8	29	850
SRW-609	4.5	3-1/8"ODF	3/8"	6"	14-1/2	19-3/8	29	850
