Key Features of solar power system :
- Good load capability, Powerful for wide applications
- Battery rated for 2,000 complete charge/discharge cycles and 10-year battery life, Battery shelf-life (no charging) greater than a year
- Battery charge time < 2.5hrs (from a fully discharged battery-pack)
- Integrated battery protection / charge control module
- Compact design, Portable style
- Both Solar and AC charging way, solar charging is prioritized, but when solar power is weak, you can manually switch to AC charging way
- Three-stage charging way, ensure a sufficient charging but no over charge
Lithium-ion Battery Solar power system
2015 hot solar portable generator power for home, for africa, for rural area
Model |
MS-300PSS |
MS-600PSS |
MS-1000PSS |
|
Built-in Battery |
Battery Type |
LiFePO4 Battery |
||
Rated Voltage |
12.8V |
|||
Battery Capacity |
30AH |
50AH |
100AH |
|
Cycle Life |
2000+ cycles |
|||
Solar Charge Input |
Input Voltage |
17VDC-22VDC |
||
Max. Input Power |
1000W |
|||
Max. Input Current |
15A |
|||
Indicator |
LED indicator |
|||
AC Charge Input |
AC Input Voltage |
185VAC--260VAC |
||
Max Charging Current |
15A |
|||
Charging Efficiency |
≥95% |
|||
Indicator |
LED indicator |
|||
|
AC Output Via Inverter |
Wave Form |
Pure Sine Wave |
||
Total Harmonic Distortion |
≤5% at nominal power |
|||
Continuous Power |
300W |
600W |
1000W |
|
Peak Power |
600W |
1200W |
2000W |
|
AC Output Voltage |
220V±5% |
|||
Frequency |
50Hz±5% |
|||
Charging Efficiency |
≥85% |
|||
Indicator |
LED indicator |
|||
DC Outputs |
USB Output Voltage |
5V |
||
USB Output Current(2 options) |
1000mA or 2100mA |
|||
Cigarette Lighter Output Voltage |
12V |
|||
Cigarette Lighter Output Current |
10A |
|||
|
Note: the above models are our popular ones, we can also customize it according to your specified requirement.(solar charging, AC charging, Integrated Charge Controller, inverter or UPS switching function) | ||||
1. Highly integrated multi-function portable solar power system for small homes
2. Integrated with charging & discharging controll, inverter, energy storage functions.
3. Good load capability. Powerful for wide applications with AC load (AC220V/50Hz or AC110V/60Hz), and DC load (5V/12V).
4. Robust, compact, lightweight, energy-saving, for home use, for outdoor use
5. Built-in Lithium battery. Lead acid battery optional.
6. Lithium battery cycling times over 2000. Battery shelf-life one year.
7. 300w 600w 1000w 1500w 2000w 5000w available, with 110-220V outputs and dc outputs.
8. Perfect for outdoor operation and outdoor activities, including outdoor data collection, farming, geological survey, archeology,
meteorological forecasting, fishing, mining, oil drilling, military application, as well as camping etc.
9. CE RoHS certified
10. OEM ODM.
Solar Generator System Solar Generator System Solar Generator System Solar Generator System
Solar Generator System Solar Generator System Solar Generator System Solar Generator System
Q1: What kind of loads(home appliances) can be used with the solar generator?
A1: It fits for the loads which the rated power are under 5000W, such as the computer, printer, TV, lights, fan, laptop, small fridge etc.
Q2: Can I use the loads at one time?
A2: It depends, the total power of the loads must be less than or equal to 5000W.
Q3: How many hours can it last for my loads?
A3: It depends on the power of the loads. For example:
One desktop computer, it lasts 9 hours around after fully charged.
One laptop, it lasts 27 hours around after fully charged.
Q4: How many hours should I charge it with your recommended panel?
A4: Around 8 hours to charge the battery fully (at STD condition).
Q5: When do I need to use the AC charger?
A5: For the continuous overcast days, or in some special cases, such as emergency purpose for outing.
Q6: Can I charge it by solar and AC at one time?
A6: Yes, it can be faster fully charged then.
Q7: Can I discharge the system while charging?
A7: Yes, and it will take longer time to fully charge the battery.
Q8: What place for these power generator used for?
A8: For home use, for remote area, and can be also rent to others
