Home > Electrical & Electronics > Connector & Terminals > Wire to Wire Connector > B Series Push-Pull Self-Latching Circular Connector

B Series Push-Pull Self-Latching Circular Connector

B Series Push-Pull Self-Latching Circular Connector photo-1

B Series Push-Pull Self-Latching Circular Connector photo-2

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Model Number:

JGG-CGG 00/0B/1B/2B/3B

Type:

Other, B series push-pull circular connector

Contact Supplier Request Quote Chat Now

Yangzhou Jingcheng Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Model Number JGG-CGG 00/0B/1B/2B/3B

Type Other, B series push-pull circular connector

Application Other, Audio & Video

Gender Other

B series

Low voltage push-pull connectors for data, signal, electrical and power use!

MOCO connectors are used in instrumentation, medical devices, and anywhere a high density, high reliability, quick mating connector is needed.

These high precision connectors. With a life span greater than 5000 insertions,

complete EMC shielding, shock resistance, vibration resitance, and corrosion resistance this is the highest quality connector on the market.

Main features:

-Security of the push-pull self-latching system;

-Multipole types 2,3,4 contacts;

-Solder or print contacts(straight or elbow);

-High packing density for space savings;

-Multiple key options to avoid cross mating of similar connectors;

-Keying system for connector alignment;

-360°screening for full EMC shielding;

-Pull-away plugs with lanyards available.

Specifications

Endurance (Shell) Humidity (max): <=95% [at 60 deg C /140 F]

Vibration: 15 g [10 Hz - 2000 Hz]

Shock Resistance: 100 g [ 6 ms]

Salt Spray Corrosion: >144 hr

Climatical Category: 50/175/21

Shielding (min): 75 dB (10 MHz)

Shielding (min): 40 dB (1 GHz)

IP Rating:50

Product details
1.Shell size	00 to size 3(#00,#0,#1,#2,#3)
2. Multi-pole types	2 to 32 contacts
3. Security	push-pull self-latching system
ntacts (straight or elbow)	Solder ,print or crimp
5.Packing	High packing density for space saving
7.Key options	0°,30°,45°,60°
8. Male contacts and female contacts	brass with gold-plated surface
9. Out shells	brass with chrome nickel-plated surface
10. Insulator	PPS and PEEK
11.Screening	360 angle screening for full EMC shielding.
12. Compatible with Lemo® Series B, includingFGG,FAG,FHG,EGG,EGA,ECG,ECA,PHG,EPG,EXG.such as:	FGG.0B.303.CLAD42z FGG.0B.304.CLAD52z FGG.0B.305.CLAD42

	FAG.0B.302 FAG.0B.303 FAG.0B.304 FAG.0B.305 FAG.0B.306 FAG.0B.307

	FHG.0B.302 FHG.0B.303 FHG.0B.304 FHG.0B.305 FHG.0B.306 FHG.0B.307

	EGG.0B.302 EGG.0B.303 EGG.0B.304 EGG.0B.305 EGA.0B.302 EGA.0B.303

	ECG.0B.302 ECG.0B.303 ECG.0B.304 ECG.0B.305

	ECA.0B.302 ECA.0B.303 ECA.0B.304 ECA.0B.305

	PHG.0B.302 PHG.0B.303 PHG.0B.304 PHG.0B.305 PHG.0B.306 PHG.0B.307

	EPG.0B.302 EPG.0B.303 EPG.0B.304 EPG.0B.305 EPG.0B.306 EPG.0B.307

	EXG.0B.302 EXG.0B.303 EXG.0B.304 EXG.0B.305 EXG.0B.306 EXG.0B.307
FGG, FAG, FHG, PHG, EGG, EGA, ECG, ECA, EPG, EXG, B/K/S/F/P series, ODU, Fischer, Hirose, binder and redel connectors is available.

Yangzhou Jingcheng Electronics Co.,Ltd a well-known manufacturer and supplier specialized in the development, manufacture and sale of R.F coaxial connectors, cable assemblies, matched terminals, micro-wave components and communication structure products, is located in Bali industrial Park,yangzi River South Rd.yangzhou,jiangsu.China.

We manufacture the following products:
1) RF coaxial connectors and adapters
2) Flexible, semi-flexible and semi-rigid Cable Assemblies

Our Quality:

Quality is the life of jingcheng. We use only the best quality (original) components to ensure the standard of our product range is of the highest caliber.All products we sold out are strictly selected and tested by our QC department.

Warranty:

We provide comprehensive after-sales service, including quality service, guidance services,We focus on customer needs in every detail.Please contact us if you need our detail warranty term.

Payment:

We accept payment via TT (Bank transfer), Western Union,

We accept bank transfer for large orders. For small order, you'd better pay via Western union

Shipping:

We offer as many shipping options as possible, including DHL, UPS, TNT and Fedex
