LCD digit Water Meter

Specifications

Removable woltman cold water meter
This type of water meter can be used for a remote reading transmission system as

LCD DISPLAY.

Feature:
--Removable element structure, easy installation and maintenance, register for universal use within this range detachable without Removing the meter from the pipeline;
--Dry-dial, Magnetic drive sensitive action, small pressure loss;
--Vacuum sealed register ensures the dial keep free from fog and Keep the reading clear in a long term service;
--Selected high quality materials for steady & reliable characteristic;
--Technical data conform to international standard ISO 4064.

Working condition
Water temperature: 0.140 ( 0.190 for hot water meter)
Water pressure: ≤1Mpa (1.6MPa for special requirement)



 MAIN TECHNICAL SPECIFICATIONS



Type	Size   (mm)	Class	qs	qp	qt	qmin	Min. Reading	Max. Reading
			m3/h				m3
LXLC-50	50	A	30	15	4.5	1.2	0.0002	999,999
		B			3.0	0.45
LXLC-65	65	A	50	25	7.5	2.0	0.0002	999,999
		B			5	0.75
LXLC-80	80	A	80	40	12	3.2	0.002	999,999
		B			8.0	1.2
LXLC-100	100	A	120	60	18	4.8	0.002	999,999
		B			12	1.8
LXLC-125	125	A	200	100	30	8	0.002	999,999
		B			20	3
LXLC-150	150	A	300	150	45	12	0.002	999,999
		B			30	4.5
LXLC-200	200	A	500	250	75	20	0.002	999,999
		B			50	7.5
LXLC-250	250	A	800	400	120	32	0.002	999,999
		B			80	12
LXLC-300	300	A	1200	600	180	48	0.02	9,999,999
