Home > Products > Accessories /Fittings > brass body of water meter
brass body of water meter
- 100000 Piece / Pieces per Month
- Shanghai Chongqing
- T/T D/P D/A
Product Details
Place of Origin: | Chongqing, China | Brand Name: | GALON | Model Number: | GL-SP |
Product Description
Specifications
brass water meter bodyBronze body, 59% copper, high quality.
OEM and design.
1. material: casting brass water meter body or bronze, nylon plastic.
2. type: Vertical or horizontal, for single jet or multi jet.
3. size: 15-50mm for multi jet, 15-40mm for single jet.
4. inside or outside adjustment. Surface plated paint or natural color
5. with screw and plastic strainer.
6. copper contain according to customer's request.
Multi-jet, dry-dial, easy for maintenance;
--Magnetic drive reliable characteristic, long working life;
--ISO4064 Class B
Application:
--Measuring the total volume of cold portable water passing through the pipeline.
Feature:
--Multi-jet, dry-dial, easy for maintenance;
--Magnetic drive reliable characteristic, long working life;
--Vacuum sealed register ensures the dial keep free from fog and frost, Keep the reading clear in a long term service;
--Technical data conform to international standard ISO4064 Class B
Working condition:
Water temperature: 0.1°C~40°C for cold water meter .
0.1°C~90°C for hot water meter.
Water pressure : ≤1.0Mpa or 1.6Mpa
Maximum permissible error:
(1) in the lower zone from qmin inclusive up to but excluding qt is ±5%.
(2) in the upper zone from qt inclusive up to and including qs is ±2%;
Hot water meter ±3%
Contact Us
- Chongqing Galon Meter Co., Ltd.
- Contact nameAlexander GL
- Phone86-23-88161878
- Address13-9, No. 4-1, Qiaobeiyuan
