LR-LINK LREC9802BF-2SFP+ PCIe x8 Dual Optical 10G SFP Network Card Compatible With Intel 10G Card X520-SR2
Dual-Port 10 Gigabit SFP+ Ethernet Server Adapters Card Provide Ultimate Flexibility and Scalability in Virtual and Unified Storage Environments
Product Description:
LR-LINK 10g Network Card Compatible with Intel 10g card x520-sr2 with SFP+ connectivity are the most flexible and scalable Ethernet adapters for today’s demanding data center environments. Data center networks are being pushed to their limits. The escalating deployments of servers with multi-core processors and demanding applications such as High Performance Computing (HPC), database clusters, and video-on-demand are driving the need for 10 Gigabit connections. Customers require flexible and scalable I/O solutions to meet the rigorous requirements of running mission-critical applications in virtualized and unified storage environments.
10G SFP Card Product Picture Showing:
Best Choice for Virtualization
Intel’s family of LR-LINK LREC9802BF-2SFP+ 10g sfp card addresses networking bottlenecks in virtualized environments. These adapters enable network-intensive applications to achieve the performance expected in a virtualized environment.
The LR-LINK LREC9802BF-2SFP+ intel chip 10g card delivers the same functionality and throughput as ten dual-port, one gigabit adapters, saving cost, power, and complexity.
Unified Networking and Storage
The family of LR-LINK Network Card Brand LREC9802BF-2SFP+ 10G sfp network card lowers your data center total cost of ownership (TCO) by providing the ability to route LAN and SAN traffic over a single fabric.
Support for FCoE
FCoE encapsulates Fiber Channel frames over standard Ethernet networks, enabling Fiber Channel to take advantage of 10 GbE networks while preserving its native protocol. The LR-LINK LREC9802BF-2SFP+ 10g network card compatible with x520-sr2 offer FCoE hardware acceleration to provide performance comparable to FC HBAs. The server adapters support Data Center Bridging, also known as Converged Enhanced Ethernet (CEE), which allows customers to configure traffic classes and priorities to deliver a lossless Ethernet fabric. An Intel Ethernet X520 server adapter reduces TCO by eliminating redundant fabrics and saves the cost of expensive FC HBAs and FC switch ports.
Support for iSCSI
The server adapters provide complete support for proven native OS and VMM iSCSI initiators as well as iSCSI boot.
The LR-LINK LREC9802BF-2SFP+ 10g sfp card do it all 10 Gigabit LAN, FCoE, and iSCSI; truly delivering on the promise of unified networking.
Reliable Performance
The family of LR-LINK LREC9802BF-2SFP+ 10g network card include a number of advanced features that allow it to provide industry-leading performance and reliability.
Security Optimizations
The adapters support IPsec offload for Microsoft’s Network Access Protection (NAP), Active Directory,* and future security capabilities in Windows* 7. An LR-LINK 10G server adapter allows customers to run a secure network environment without sacrificing performance.
PCIe v2.0 (5 GT/s)
PCIe v2.0(5GT/s) support enables customers to take full advan- tage of 10 GbE by providing a maximum of 20Gbps bi-directional throughput per port on a single dual port card.
Designed For Multi-core Processors
Support for technologies such as multiple queues, receive-side scaling, multiple MSI-X vectors, and Low Latency Interrupts allow the LR-LINK LREC9802BF-2SFP+10g network card to provide high-performance, 10 Gigabit connectivity in multi-core server blades. These technolo- gies distribute network processing across multiple CPU cores, improving overall performance.
General
Low-profile
Load balancing on multiple CPUs
iSCSI remote boot support
Support for NOS
Intel® PROSet Utility for Windows* Device Manager
Time Sync (IEEE 1588, 802.1as)
I/O Features for Multi-core Processor Servers
Intel® Direct Cache Access (DCA)
MSI-X support
Low Latency Interrupts
Header Splits and Replication in Receive
Multiple Queues: 128 Tx and Rx queues per port
Tx/Rx IP, SCTP, TCP, and UDP checksum offloading (IPv4, IPv6) capabilities
Receive and Transmit Side Scaling for Windows environment and Scalable I/O for Linux* environments (IPv4, IPv6, TCP/UDP)
IPsec Offload
MacSec
Virtualization Features
VMDq
Next-Generation VMDq1 (64 queues per port)
PC-SIG SR-IOV Implementation (64 virtual functions per port)
Virtual Machine Load Balancing (VLMB)
VLAN support with VLAN tag insertion, stripping and packet filtering for up to 4096 VLAN tags
Manageability Features
Preboot eXecution Environment (PXE) Support
Simple Network Management Protocol (SNMP) and Remote Network Monitoring (RMON) Statistic Counters
ISCSI Boot
Watchdog Timer
Adapter Product Features
Intel® PROSet Utility
Receive Side Scaling
Direct Cache Access (DCA)
Advanced Software Feature
Teaming support
IEEE 802.3ad (link aggregation control protocol)
PCIe Hot Plug*/Active periphera; component interconnect (PCI)
IEEE 802.1Q* VLANs
IEEE 802.3 2005* flow control support
(UDP), Internet protocol (IP)
IEEE 802.1p*
TCP segmentation large send offload
MSI-X supports Multiple Independent Queues
Interrupt moderation
IPv6 offloading — Checksum and segmentation capability extendedto new standard packet type
