Glass bottle beer filling machine (crown cap)
Introduction
1.This glass bottle beer filling machine (crown cap) is suitable for packing beer or gas containing beverage. Its performance is as following: all parts, for instance, filling valve, which directly contact medium are made of stainless steel or harmless material. So it conforms to the requirements of Food sanitation.
2.Sealing parts are made of heat-proofing rubber, in order to meet the technique requirements of users to sterilization at high temperature.
3.Using programmable controller to realize fully automatic control
4.Beer filling machine uses transducer as speed regulator, so the user can regulate the machine easily to suit different power requirements.
5.It adopts equal pressure filling principle and current spring valves in order to assure beverage quality.
6.Using advanced magnetic coupler to regulate cap-screwing torque, in order to assure capping quality
Main Technical Specifications of the beer filling machine
Model | BDGF18-18-6 | BDGF24-24-8 | BDGF32-32-10 | BDGF40-40-12 |
Production Capacity (500ml) (B/h) | 4000 | 6000-8000 | 8000 | 12000 |
Washing Heads | 18 | 24 | 32 | 40 |
Filling Heads | 18 | 24 | 32 | 40 |
Capping Heads | 6 | 8 | 10 | 12 |
Suitable Bottle and Cap | Glass Bottle; ROPP cap | |||
Suitable Bottle Size | Round or Square | |||
Diameter of Bottle (mm) | Φ50-Φ110 | |||
Height of Bottle (mm) | 150-340 | |||
Filling pressure (Mpa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 |
Power Consumption (KW) | 3.5 | 4.5 | 6.5 | 7.5 |
Dimension (mm) | 2450*1800*2350 | 2780*2200*2350 | 3600*2650*2350 | 3800*2950*2400 |
Weight (kg) | 3500 | 4500 | 5500 | 8000 |
Washing Part
Filling Part
Filling and Capping Part of the glass bottle filling machine
Factory, Workings and Packing
Hyford keeps 100% confident and try our best ability to satisfy customers' requirements with their selected products. Additionally, Hyford owns a professional aftersale customer service team. Therefore, If you have any inquiries or questions, please visit our store, have a look other products and leave your message. Your message will be highly appreciated! Welcome to Hyford!
