Help CenterAutomatic NC Spray Painting Machine FME40
Related Products
-
Automatic Spraying Paint Equipment FME40 for WoodlineNegotiableMOQ: 1 Set -
FME40 Easy Used Paint/painting/coating Machine for WoodlineNegotiableMOQ: 1 Set
-
Best Quality Spray Painting Machine for WoodlineNegotiableMOQ: 1 Set
-
FME40 Electric Spraying Paint Machine for WoodlineNegotiableMOQ: 1 Set
-
FME40 Excellent Spray Painting Equipment for DoorframeNegotiableMOQ: 1 Set
Product Description:
Standard Technique Parameters | |
Dimensions |
6.5*2.3*2.2 (m) |
Weight of the machine |
1000 kg |
Min processing length |
700 mm |
Max processing width |
70 - 300 mm |
Max processing height |
5 - 80 mm |
Conveying speed |
10 - 15 m/min |
Transmission power |
0.75 KW |
Fan power |
1.5 KW |
Pump power |
0.75 KW |
Working gun |
6 |
Gun caliber |
0.8/1.0/1.3 mm |
Types of paint |
PE, PU, UC, NC, UV, Waterborne paint |
The amount of paint used |
60-200g/ m² |
Air pressure |
0.6MPA |
Air flowing |
2400L/min |
Power supply |
380V 50HZ (three-phase four-wire power line power supply) |
| Features: |
|
1. PLC controller controls each spray gun’s switch independently.
2. Automatic identification infrared sensor is provided to test the product’s length and width. PLC adjusts spray gun’s position automatically.
3. The automatic spray gun is imported from Japan originally — Anest or Meiji spray gun. Each spray gun can be control separately.
4. Equipped with Waste gas purification system.
5. Stable paint supply is offered by a set high-capacity diaphragm pump and stabilizer.
6. The conveyor’s speed can be frequency conversion.
7. The paint recovery device can recycle 70%-80% wasted painting. |
Packing:
How to distinguish between genuine and fake:
My machine have the Patent certificate of the People's Republic of China as below:
The contact way of our company:
