Help CenterMultifunctional Magic and High-Quality Spray Paint Machine for the Wooden Door in Foshan(FXF250-MYW)
Related Products
-
2016 New Fully Automatic Wooden Door Numerical Control Spray Painting MachineNegotiableMOQ: 1 Set -
2016 New Top Quality Automatic Spray Paint Machine Series Wooden-DoorNegotiableMOQ: 1 Set
-
2016 Goods Shelves the Door Professional Automatic Paint Spraying MachineNegotiableMOQ: 1 Set
-
Top Popular Wood Door Full Automatic Spray Paint MachineNegotiableMOQ: 1 Set
-
2016 Popular Product Dedicated for Wood Door Used Spray Paint MachineNegotiableMOQ: 1 Set
Product Picture:
Product Description:
1.The pneumatic rotary double-positioning feeding and automatic turnover mechanism enables the machine to paint the door's six sides once time which saves working procedures, improve efficiency and ensure the painting effect.
2.Only need two ordinary workers to finish the whole process. The capacity is 160-190 doors per day(8 hours).
3. Touching type computer digital operation machine or automatic detection machine are provided. Both of them are easy to learn. Controlling the spray gun's moving route through the computer to imiate manual painting, which ensures smooth painted surface and reaches the corners being painted.
4. The machine is easy to operate and not rely on painting technique. It shortens the production cycle, reduces paint cost and labor cost.
5. 2 spray guns are provided in general, while 3 spray guns can be installed at the most.
Technique parameter: | |
Maximum processing length |
2.5M |
Maximum processing width |
1.2M |
Maximum processing thickness |
0.1 M |
Spry gun running speed |
0~1800MM/S |
Spray gun caliber |
0.8/1.0/1.3 |
Servo motor(total) |
4KW |
Air pressure |
0.6mpa |
Paint type |
PE,PC,PU,UC,XU,UV,(Water paint) |
Overall sizes |
4.5 X 2.4 X 2.5M |
Notes:Various sizes and special functions can be customized according to requirements of customers. |
Company Work Environment:
Packing:
How to distinguish between genuine and fake:
My machine have the Patent certificate of the People's Republic of China as below:
The contact way of our company:
