Moisture Removal Equipment

FOB Price

USD $20,000 - $40,000 / Set

1 Set(Min.Order)

Supply Ability 1 Set / Sets per Month
Port SHANGHAI
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Type:	Flash Drying Equipment	Place of Origin:	Jiangsu, China
Brand Name:	SHEN YU	Model Number:	XSG Series	Certification:	ISO 9001:2000
Warranty:	three years	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Description:

XSG series rotating flash dryer is a kind of new equipment, which is developed basing on advance technology abroard. It eliminates environmental pollution and the entire machine performance can reach the international 1990's advance level. Drying, grinding and sieve are completed in one equipment at a time.

Features:

1. It combines the rotational flow technology with smashing and classification technology.

2. Compact structure, resonable design and high production efficiency.

3. Feeding device can be chose according to your needs, and charging process is continuous and stable.

4. With air pressure equipment and shaft equipment, it can longer the life of machine.

Application:

1.Organic Material:

PE, rhoda mine,101Gel, cadmium laureate, benzoic acid, germicide, sodium oxalate, cellulose, aminophenazone, 4-PABA, etc.

2.Inorganic Material:

acetate fiber, rock quartz, mud conditioner,borax, calcium, carbone, hydroxide, copper sulfate ferric oxide, barium carbonate, antimony trioxide, all kind of metallic hydroxide, all kinds of heavy metallic salt, synthetic,etc.

3.Ceramic Industry:

kaolin,silica, alumina clay,etc.

4.Dyestuff Industry:

anthraquinone, black ferric oxide, indigo blue pigment, butyric acid, titanium hydroxide,zinc sulfide.

5.Food Industry:

starch, soybean protein,GLU, soya protein, agglomerative starch, wheat starch,etc.

Technical Parameter:

Model	XSG-2	XSG-4	XSG-6	XSG-8	XSG-10	XSG-12	XSG-16	XSG-20
ID of main machine,mm	200	400	600	800	1000	1200	1600	2000
Air amount,M3/h	350-500	1150-2000	2450-4500	4450-7550	7000-12500	10000-20000	18000-36000	28200-56500
Evaporated moisture,kg/h	12-17	40-70	80-150	150-250	230-4250	300-600	600-1000	1000-1500
Max equipped capacity,kw	10	20	40	65	85	105	150	230
Max,hight,m	4.0	4.8	5.8	6.5	7.1	7.8	8.8	10.1
Occupied area ,m 2	15	20	28	35	40	52	80	150

Contact Us

Changzhou Xingyu Drying Equipment Co., Ltd.: Contact nameRobert Xie; Phone86-519-83998218; AddressWanda Plazza No.88 Tongjiang(M) Road Changzhou,Jiangsu
