2015 New Product SPC01 Embedded Compass Pressure Module Sensor Module

Product Description
SPC01 atmospheric pressure compass module is a multi-function module including atmospheric pressure,height,temperature,electronic compass,according to market demands. It can be used for various of handheld device and Auto electronic tracking products'secondary development.This module adopts I2C interface to save more of your system resources and time.



Features:

*Highly integrated small size
*Data accuracy
*Sleep current is small
*Operating Current: 1.5mA
*Compass calibration level:
*Precision calibration algorithm hard magnetic compensation algorithms

Application:
*Phone/PDA
*Radio
*Outdoor handheld devices
*Carabiner
*Mine rescue
*Travel 3D navigation, blind compensation
*Sports watch
*LBS service



Elecrtronic specification

performance
Parameter Condition Unite
Minimum typical Maximum
Working voltage 2.4 3 3.6 v
Absolute pressure error ±1.5 hpa
Absolute pressure resolution 0.01 hpa
Relative pressure error ±0.12 hpa
Relative pressure resolution 0.01 hpa
Relative height error ±1 m
Relative height resolution 0.1 m
Absolute height error ±12 m
Absolute height resolution 0.1 m
Compass error horizontally ±3 °
Compass Resolution 1 °
Temperature error @ 25℃ -1.5 ±0.5 1.5 °c
0 ~ +65℃ -2 ±1.0 2 °c
Temperature resolution 0.1 °c
Power consumption Sleep status 2 uA
Working status 1.5 mA
Pressure 300 1100 hpa
Measuring range Height -698 8943 m
Compass 0 359 °
Temperature -40 85 °c
Operating temperature -40 85 °c
Storage temperature -40 85 °c


Pin definition

 2015 New Product SPC01 Embedded Compass Pressure Module Sensor Module

Pin number Pin name function
1 GND GROUND
2 SDA I2C Serial bus data
3 SCK I2C Serial bus clock
4 VCC Power supply
5 GND Ground
6 GND Ground
7 GND Ground



Product show:
