1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS With LNA Amplifier and Filter

1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS With LNA Amplifier and Filter photo-1
1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS With LNA Amplifier and Filter photo-2
1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS With LNA Amplifier and Filter photo-3
1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS With LNA Amplifier and Filter photo-4
1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS With LNA Amplifier and Filter photo-5
1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS With LNA Amplifier and Filter photo-6
US$ 2.3 - 3 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Yetnorson
Model Number:
YNX-PHS-GPS-Y017
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Yetnorson
Model Number YNX-PHS-GPS-Y017
Car Make Universal
Frequence Range 1575.42mhz/1602mhz
Gain(dB) 28dB±3dB
Cable Length 3000mm OR 5000mm

1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS with LNA amplifier and filter



Description of SMA Male GPS Active Antenna


i)Dielectric Antenna
Frequency 1574MHZ/1602MHz
Center Frequency:1575.42±5MHz
V.S.W.R: <1.5
Band Width 50 MHz Min. at -10dB
Impendence 50 ohm
Gain :28±3dB
Gain Coverage:≥- 4dBic at -90°~90°(over75% volume)
Power Handling : 1 watt
Polarization : RHCP


(ii)LNA
LNA Gain(Without cable) 32dB Typical
Noise Figure 1.5dB
V.S.W.R <1.5
DC Voltage 2.7V/3.0V/3.3V/5.0V/3.0V to 5.0V/other
DC Current 10mA Max



(iii)Mechanical
Weight:71g
Size 49 ×36×15mm
Cable RG174 3meters or other
Connector :SMA Plug default SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX or other
Mounting Magnetic base



(iv)Environmental
Working Temp -40°C~+85°C
Storage Temp. -45°C~+100°C
Vibration Sine sweep 1g(0-p)10~50~10Hz each axis
Humidity Humidity 95%~100%RH
Weatherproof 100% Waterproof



Product pictures of SMA Male GPS Active Antenna

1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS with LNA amplifier and filter1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS with LNA amplifier and filter

Testing of SMA Male GPS Active Antenna


1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS with LNA amplifier and filter

1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS with LNA amplifier and filter







Production of SMA Male GPS Active Antenna

1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS with LNA amplifier and filter





Company Information




We excute strict quality control system, begin with the raw material to the final finished goods inspection and packgaing, we have professioanl QC to check every step, we make sure that the customers get the well packed and workable goods.


Signal get us get closer with each other. Welcome to inquiry us.



Payment & Shipment &Lead Time

1575.42MHz SMA Male GPS Active Antenna for Dash DVD GPS with LNA amplifier and filter



































Payment Term
T/T/Western union/Paypal/Escrow/MoneyGram
As for samples, 100% full payment before production
As for official order, 30% deposit and 70% balance paid before delivery

Shipment
DHL/Fedex/UPS/TNT/EMS

Lead Time
3-5 working days for samples, 6-9 working days for bulk order





Certification

Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation!!!
If you have any question, please feel free to contact us.





Why choose us ?

1.OEM & ODM are warmly welcome

2.Good service and delivery on time

3. high gain with luxury design

4. several years manufacturing experience






  If You have Any Questions, Feel Free to Contact US



welcome to inquire,any questions and request, please feel free to contact with me!
