Help CenterSGZ-B Series High-speed Automatic Full Coating Machine
Related Products
-
Micro Automatic /Semi Automatic Full UV CoaterNegotiableMOQ: 1 Unit -
Autoamtic Spot UV Coating MachineNegotiableMOQ: 1 Unit
-
Automatic Micro Spot Uv Coating MachineUS$ 35,000 - 45,000MOQ: 1 Unit
-
Manual Coating Machine-SGS-IR920PUS$ 10,000 - 30,000MOQ: 1 Unit
-
Powder Removing MachineUS$ 20,000 - 50,000MOQ: 1 Unit
Specifications
1.Suitable for full UV coating2.Auto feeding, coating and delivery
3.High stability & efficiency
4.High speed
Features:
1.Auto feeder: High speed feeder is adopted, which is free of maintenance and stable feeding. Pile trolley can be pushed onto feeding pile table. Guild rail with help of manual feeding table can handle the either overlarge or oversmall sheets, which can not be fed by the feeder. This is optional
2.UV coating: Body of it adopts whole casting techniques featuring high precision, deformation free and good stability under high speed. The use of three-roller reverse rotating coating system gives easy adjustment to oiling quantity and good coating effect
3.UV curing: Integrated lamp cover with reflector and fan cooling system inside, which solidify efficiently. The cover is also good to keep the temperature inside to avoid coating deformation.
4.Automatic delivery: Adoption of pneumatic jogger ensure good sheet delivery. Auxiliary delivery table is equipped to take away the delivered sheets when sheets jam is there
Technical specifications:
Model |
SGZ-B740A |
SGZ-B1040A |
SGZ-B1200A |
Max.sheet size |
740X560mm |
1040X760mm |
1200X850mm |
Min sheet size |
400x280mm |
400x300mm |
440x300mm |
Substrate |
80-600gsm |
80-600gsm |
80-600gsm |
Max.Speed |
70000 s/h |
7000 s/h |
7000 s/h |
UV lamp power |
6.5kw X 3pcs |
9.75kw X 3pcs |
9.75kw X 3pcs |
Machine weight |
3800kg |
4600kg |
5000kg |
Machine dimension(LxWxH) |
10600X1450X1600mm |
10600X1750X1600mm |
10600x1910X1600mm |
