SEFM1100 multi functional laminator suitable for water-base film,glueless film and pre-glued(thermal film) laminating.Features:
SEFM-1100 automatic laminating machine is a multi-functional laminator well designed upon the market needs which suits the lamination of non-glue film, pre-glued film and water base glue film. Glueless film lamination saves energy efficiently, and solves completely the problems of environmental pollution and toxic residuum from traditional lamination. The index of laminated products via this machine complies with environmental protection standards in the world. So the machine is used widely for the lamination of labels, packing bags, food box, books, magazines, maps and drawings etc. And the laminated products will be water-proof, durable, of clear picture and good spatial effect etc.
Configuration:
1. Automatic paper feeder adopts oil-free vacuum pump to feed paper automatically. And paper can be added even when the machine is kept running.
2. Automatic paper feeding system is equipped with no paper protector, paper break protector and paper superposing protector, which are controlled by photoelectric and mechanical systems. When no paper, paper break or paper superposition occurs, the machine will stop automatically for self-protection.
3. Conveying table is furnished with air aspirator, roll pull guide and front lay etc. to guarantee paper conveying and overlap stable and regular, and paper feeding precision can be perfected effectively.
4. Automated operation is controlled by PLC system. 7.5’’color touch screen simplifies the machine operation. On the touch screen, as long as the operator inputs paper size, working speed etc., the machine can realize automated operation. And on touch screen, working status of the machine can be checked at any time.
5. High precision of chrome plated heating roller is equipped with built-in oil heating system, which has excellent performance of temperature persistence. The laminating temperature is adjustable upon applications.
6. Hydraulic pressuring system provides automatically big and steady pressure to guarantee good laminating quality.
7. For water-base lamination, double-roller tumbling coating can even film coating and adjust glue quantity on the film.
8. Glue supplying system supplies and recycles water-base glue automatically for water-base lamination.
9. Film cutter cuts film width to make it meet paper size. The cut film is left on the film release spindle.
10. Film perforating wheel perforates film edge for the automatic cut of laminated paper.
11. Automatic rewinder can roll up laminated paper automatically. And magnetic powder clutch is equipped on the rewinder to make the adjustment of rewinding tension more convenient and effective.
12. The winded paper shall be put on cutting machine for automatic cut.
Technical Specifications:
Model |
SEFM-1100 |
Max Paper Size |
1040*820mm |
Min Paper Size |
350*400mm |
Max. Laminating Speed |
40m/min |
Paper Thickness |
150-400gsm |
Gross Power |
20kw |
Weight |
2500kgs |
Overall Dimensions |
3600*2260*1900mm |
