SMA male /Fakra connector straight connector with RG174 cable GPS Antenna
- 5000 Piece / Pieces per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- (GPS antenna) mini GPS antenna 38*33*13 /LNA gain 28 dBi external gps active antenna
- High quality GPS/GLONASS/Beidou antenna 30dbi wide band
- mini extenal antenna 38*33*13 mm gps antenna with UHF connector
- gps active external antenna IP67 waterproof antenna with IPEX
- mini gps antenna IP67 waterproof magnetic antenna with IPEX connetcor
- active gps antenna magnetic antenna with IPEX connector
Product Details
Place of Origin: | Guangdong, China | Brand Name: | YNX | Model Number: | YNX-P006 |
Car Make: | all of the Car | Frequence Range: | 1575.42mhz/1602 | Gain(dB): | 28dB±3dB |
Cable Length: | 3000mm |
Packaging Details
One For Iphone 4 gps antenna with one PE bag packaging
Product Description
SMA male /Fakra connector straight connector with RG174 cable GPS Antenna
Application :
1.For GPS system,active antenna,made of Ceramic Microstrip Substrate
2. Compact Size, Light Weight, Low Profile, Easy to Assemble and Hide
3. The high gain LNA is made of low noise microwave components to ensure the sensibility of the system.
1.specification of SMA male /Fakra connector straight connector with RG174 cable GPS Antenna
Frequency (MHz) | 1575.42MHZ±1.023MHZ/1602mhz/1561MHZ |
Bandwidth (MHz) | 6MHZ |
Gain (dBi) | 28dB±3dB |
Input Impendence (Ω) | 50 |
V.S.W.R | ≤1.7 |
Consumption Electric | <10mA |
Polarization Intensity | R.H.C.P |
Supply Voltage | DC3.3~5.0V |
The Sound Coefficient | ≤1.5dB |
Axial Ratio | 3Db |
Max Input Power (w) | 50 |
Operating Temperature | -40°C~+85°C |
Storing Temperature | -40°C~+90°C |
Cable length (mm) | 3000 |
Connector Type | USB plug |
Radome Color | Black |
Weight (g) | 69 |
Fixed Mode | Magnet |
es of the SMA male /Fakra connector straight connector with RG174 cable GPS Antenna
Refund & Replacement
1. We can guarantee the product quality within one years .
2. If parts cannot work, we will return payment or replacement to you.
3. Any items must be returned in their original condition to qualify for a refund or replacement.
4. The buyer is responsible for all the shipping cost incurred.
Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation!!!
GPS antenna ,GPS CAR ANTENNA ,GPS ANTENNA GPS ANTENNA gps antenna gps antenna .gps antenna,gps antenna,gps anten
Company Profile
Shenzhen Yetnorson Technology Co.,Ltd is one of professional antenna maker, which focus on GSM/CDMA/PHS/3G/4G antenna, 2.4GHz (wi-fi, wlan)/3.5GHz (wimax)/5.8GHz/wi-fi amplifier communication antenna serial(including: all direction, yagi antennas ,3G parabolic antennas, panel antenna, indoor antenna like : ceiling mount antenna, Wall Mount Antenna, desk antenna, double polar, rubber, bandwide, card mount serial antenna. We also provide DVB-T/DMB-T/CMMB moving digital TV antenna, low frenquency antenna: 315MHz/433MHz wi-fi digital /wi-fi control /wi-fi wrote water meter/electricity meter antenna, GPS guide antenna, communicate parts, connector and so on. At present, Shenzhen Yetnorson Technology Co.,Lth.has developed more than 100 styles of antenna, with wi-fi internet, wi-fi electronic control, wi-fi end, wi-fi public telephone, wi-fi digital pass, wi-fi Satilla position, wi-fi Radio broadcasting communication field.
We offer antennas with good quality and good price. And we are cooperating with several overseas clients from all over the world. Please support us. Thank you very much!
