Specifications
uv lamp electronic ballast1.CE,CB,SAA,ROHS,ISO9001 approved
2.OEM,high quality
3.PF:0.98,THD:15%
4.Voltage:120V or 230V
uv lamp electronic ballast
1.for UV lamp 7W,9W,11W,13W,18W.
2.power factor selection:PF>0.6 or PF>0.98
2.Long life low current wave peak
3.High Power factor
4.Low Total Harmonic Distortion,low lamp current crest factor
5.EMC effection:Pass
6.Comply to EN 61347-1,EN 61347-2-3,EN 55015,EN 61547,EN 61000-3-2
7.Start mode :Preheat start or instant start selectable
8.Average useable life:>20000hrs
9.End of lamp life protection.
10.Apply plug- in wiring terminal, convenient installation
11.AC voltage range(min-max)170-264V or 90-130V
DC voltage range(min-max)198-276V
12.Energy Efficiency:EEI=A2
13.Safe switch off of defective lamps
14.Automatic re-start after lamp change.
15.Protection against lamp fault condition.
(contain End of lamp life protection.)
16.End of lamp life,over-heat,over-load protection
17.Ingress protection:IP20
Features of electronic ballast:
1. Favorable low voltae starting performance,start the lamp under 130v low voltage,power supply.
2. Apply plug-in wiring terminals,conbenient installation apply electronic soft start technology; outstanding performance,long life low current wave peak ratio,
3. The electromagetic compatibility reaches the national standard,high power factor >0.98
