Manufactuing GPS car roof antenna Auto glonass gps antenna with magnet
- 20 Piece / Pieces per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- Magnetic base active Navigation GPS Antenna 1575.42MHz auto gps antenna
- Yetnorson Magnetic base GPS Antenna high performance auto glonass gps antenna
- Waterproof IP67 car gps antenna with magnet GPS antenna with Fakra code C connector
- Manufactuing Active GPS antenna auto GPS antenna with magnet
- Passive GPS elements AUTO GPS antenna with magnet
- Active GPS assemblies GPS antenna for tracking
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Yetnorson | Model Number: | YNX-TLB-003-external car gps antenna |
Car Make: | Universal | Frequence Range: | 1575Mhz | Gain(dB): | 29dbi |
Cable Length: | 3000mm±10mm |
Packaging Details
1pcs antenna/PE bag. 200pcs/CTN for Auto glonass gps antenna with magnet
Product Description
Specifications
Manufactuing GPS car roof antenna,1) 29dbi auto gps antenna
2)VSWR:1.5 auto antenna
3) 1575.42MHz
4)SGS,,CE,ROSH
Manufactuing GPS car roof antenna Auto glonass gps antenna with magnet
Welcome to Shenzhen Yetnorson technology Co., LTD.
The advantage of Manufactuing GPS car roof antenna Auto glonass gps antenna with magnet
1,rich experience , proven technique
2,low price and high gain
3,wider frequency
Specifications of Manufactuing GPS car roof antenna Auto glonass gps antenna with magnet
Electrical Specification of Manufactuing GPS car roof antenna Auto glonass gps antenna with magnet | |
Center Frequency (MHz) | 1575.42MHZ±2MHZ |
Bandwidth (MHz) | 6MHZ |
Gain (dBi) | 29dB±3dB(LNA) |
Input Impendence (Ω) | 50Ω |
V.S.W.R | ≤1.8 |
Consumption Electric | <10mA |
Polarization Intensity | R.H.C.P |
Supply Voltage | DC3.3~5.0V |
ESD-Compliant | SJ/T 10694 |
Testing voltage(KV) | 15 |
The Sound Coefficient | ≤1.5dB |
Axial Ratio | 3dB |
Max Input Power (w) | 50 |
Operating Temperature | -40°C~+85°C |
Storing Temperature | -20°C~+85°C |
Cable length (mm) | 3000 |
Connector Type | FAKRA C (Blue) |
Radome Color | Black |
Dimension-mm | Φ72 x 21 |
Weight (g) | 140 |
Electrical Specifications of Manufactuing GPS car roof antenna Auto glonass gps antenna with magnet | |
Frequency Range (MHz) | 900-1800Mhz |
Input Impendence (Ω) | 50 |
V.S.W.R | ≤1.5 |
Gain (dBi) | 3.0 |
Polarization Type | Vertical |
Radiation Direction | Omnidirectional |
Max Input Power (w) | 50 |
Operating Temperature | -40°C~+85°C |
Storing Temperature | -20°C~+85°C |
Cable length (mm) | 3000 |
Connector Type | SMA |
Radome Color | Black |
Dimension-mm | Φ72 x 21 |
The appearance of Manufactuing GPS car roof antenna Auto glonass gps antenna with magnet
GPS GSM Antenna GPS GSM Anten GPS GSM Antenna
1. We can guarantee the product quality within one years
2. If parts cannot work, we will return payment or replacement to you.
3. Any items must be returned in their original condition to qualify for a refund or replacement.
4. The buyer is responsible for all the shipping cost incurred
Shenzhen Yetnorson technology Co., LTD. as one of the emerging high-tech enterprise.Who is one of the leader who is engaged in the antenna products .custom service, R&D, design,Our main prooducts at GSM/GPS/CDMA/DVB-T/DMB-T/DAB-T/ISDB /PHS / 3 G / 4 G /5.8G, 2.4 GHz (WIFI, wireless local-area network (wlan)-/ 3.5 GHz wimax (5.8 GHz) / wireless spread spectrum communication series
1,Q:what is you brand ?
A: Yetnorson antennas
2,Q:how can i get the sample ?
A: if you need sample to test ,please pay for the shipping cost ,there we can free for one sample to you
3,Q: how much the shipping cost will be for sample ?
A :The depend on the weight and packing size you are
4, Q :how can i get the price list ?
A :please send the email and order information for us , so we can give the latest price for you
5.Q:Can you give me the deliver time?
A: Delivery time is approx. 14 to 25 business days (excluded Saturday & Sunday, Public Holiday) to most US/UK/AU destinations
1) Australia - 7-14 working days
2)UK/ Canada - 14-21 working days
3)Europe & Ireland - 18-24 working days
4)Brazil/ South America - 30-40 working days
5)Russian Federation:30-50 working days,we suggest you choose hk post
Manufactuing GPS car roof antenna Auto glonass gps antenna with magnet
Company Profile
Shenzhen Yetnorson Technology Co.,Ltd is one of professional antenna maker, which focus on GSM/CDMA/PHS/3G/4G antenna, 2.4GHz (wi-fi, wlan)/3.5GHz (wimax)/5.8GHz/wi-fi amplifier communication antenna serial(including: all direction, yagi antennas ,3G parabolic antennas, panel antenna, indoor antenna like : ceiling mount antenna, Wall Mount Antenna, desk antenna, double polar, rubber, bandwide, card mount serial antenna. We also provide DVB-T/DMB-T/CMMB moving digital TV antenna, low frenquency antenna: 315MHz/433MHz wi-fi digital /wi-fi control /wi-fi wrote water meter/electricity meter antenna, GPS guide antenna, communicate parts, connector and so on. At present, Shenzhen Yetnorson Technology Co.,Lth.has developed more than 100 styles of antenna, with wi-fi internet, wi-fi electronic control, wi-fi end, wi-fi public telephone, wi-fi digital pass, wi-fi Satilla position, wi-fi Radio broadcasting communication field.
We offer antennas with good quality and good price. And we are cooperating with several overseas clients from all over the world. Please support us. Thank you very much!
