Dry Cement Discharge Service

Name: Dry Cement Discharge Service
Brand: Minghose
Price: USD $9.59 - 89.29 / Piece

FOB Price

USD $9.59 - $89.29 / Piece

1 Piece(Min.Order)

Supply Ability 1000 Piece / Pieces per Month
Port Tianjin Port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Hebei, China

Brand Name:

Minghose

Model Number:

DCDS65

Product Description

DRY CEMENT DISCHARGING HOSE -1/8” SBR TUBE

low pressure material transfer hose designed for discharge service of dry cement and powered abrasive materials.

Lightweight construction provides superior flexibility without sacrificing quality.

Premium grade cover resists cuts,scuff,and ozone attack .

Tube: 1/8” Extruded SBR.

Reinforcement: Synthetic, High tensile textile

Cover: Black SBR

Temperature:-40°F to + 150°F.(-40°C to +66°C)

Coupling: Hammer Union, Tank Union, etc. Hose assembly is electrically continuous unless otherwise specified by customer.

I.D		0.D		REINFORCEMENT	WORKING PRESSURE PSI		WEIGHT LB/FT
(in)	(mm)	(In)	(mm)	REINFORCEMENT	(psi)	(bar)	(lb/ft)	(kg/m)
4	101.6	4 1/2	114.3	2piles	65	4.48	1.49	1.00
4 1/2	114.3	5	127	2piles	65	4.48	1.67	1.12
5	127152.4	5 1/2	139.7	2piles	65	4.48	1.84	1.24
6		6 1/2	165.1	2piles	65	4.48	2.24	1.50

Dock Hose 225PSI

APPLICATION:

Built with a corrugated cover to provide flexibility in petroleum transfer service. A variety of tube compounds are available to tailor the chemical and hydrocarbon resistance of the hose to the type of material handled.

CONSTRUCTION:

Tube: Nitrile synthetic rubber for up to 50% aromatics.

Cover: Black synthetic cover, corrugated, wrapped finish

Reinforcement: Spiral-plied heavy-duty synthetic fabric with double wire helix

Temperature: -25°F to 200°F (-32°C to 93°C)

COUPLING

Coupled with standard built-in steel nipple/150#RFSO flanges. Available in other bolt hole patterns, materials and floating flanges on request. Swage nipples are offered up to 10". Hose assembly is electrically continuous unless otherwise specified by customer.

ID		OD		MAX. WP		BEND RADIUS		VACUUM HG		WEIGHT
in.	mm.	in.	mm.	psi	Mpa	in.	mm.	in.	mm.	lb./ft.	kg./m.
3	76.2	3.89	98.8	225	1.55	11	279	29	737	3.28	4.88
4	101.6	5.29	134.4	225	1.55	15	381	29	737	6.30	9.38
6	152.4	7.34	186.4	225	1.55	22	559	29	737	9.50	14.14
8	203.2	9.43	239.5	225	1.55	30	762	29	737	13.81	20.55
10	254.0	11.63	295.4	225	1.55	40	1016	29	737	20.49	30.49
12	304.8	13.72	348.5	225	1.55	60	1524	29	737	25.13	37.40

Note: Working pressure 300PSI is available

Hot Tar & Asphalt

APPLICATION:

Designed for petroleum-based products up to 350°F between docks and tankers or barges under heavy-duty conditions.

CONSTRUCTION:

Tube: Nitrile synthetic rubber, flat steel wire helix supporting the tube

Cover: synthetic rubber

Reinforcement: Spiral-plied synthetic fabric with wire helix

Temperature: -25°F to 350°F (-32°C to 177°C)

COUPLING

Coupled with galvanized built-in steel nipple/150#RFSO flanges. Available in other bolt hole patterns, materials and floating flanges on request. Smooth bore assembly is electrically continuous unless otherwise specified by customer.

ID		OD		MAX. WP		BEND RADIUS		VACUUM HG		WEIGHT
in.	mm.	in.	mm.	psi	Mpa	in.	mm.	in.	mm.	lb./ft.	kg./m.
4	101.6	5.28	134.1	225	1.55	36	914	29	737	6.48	9.64
6	152.4	7.72	196.1	225	1.55	48	1219	29	737	13.83	20.58
8	203.2	9.80	248.9	225	1.55	60	1524	29	737	19.11	28.44
10	254.0	11.80	299.7	225	1.55	80	2032	29	737	23.20	34.52

Dock Return Hose

APPLICATION:

For use in the recovery of petroleum vapors during the transfer of petroleum-based products, Cooling Water, Exaust Gasses between docks and tankers or barges.

CONSTRUCTION:

Tube: Nitrile synthetic rubber, flat steel wire helix supporting the tube

Cover: synthetic rubber

Reinforcement: Synthetic fabric plies plus two (2) wire helix

Temperature: -25°F to 200°F (-32°C to 93°C)

COUPLING

I.D		0.D		BEND RADIUS		WORKING PRESSURE PSI		WEIGHT LB/FT		VACUUM
(in)	(mm)	(In)	(mm)	(in)	(mm)	(psi)	(bar)	(lb/ft)	(kg/m)	VACUUM
5	127	5 3/4	146 1/20	20	508	75	5.17	4.00	2.69	FULL
6	152.4	6 3/4	171 9/20	24	609.6	65	4.48	4.60	3.09	FULL
8	203.2	8 7/8	225 17/40	36	914.4	50	3.45	6.80	4.57	FULL
10	254	10 7/8	276 9/40	48	1219.2	40	2.76	10.30	6.92	FULL

SLURRY HOSE

Application: Primarily designed for handling abrasive slurries in mines and quarries. Can also be used for dry material handling of sand,gravel,grain,slag,

and other such materials. External re-usable bolt on flanges allow for ease of installation,and uninterrupted free flow.

Cover: Think black corrugated abrasion and weather resistant synthetic blend. Specially compounded to stand up to heavy abuse in mines and quarries.

Reinforcement:Multiple layers of high tensile synthetic cords enveloping an extra heavy duty wire helix.

Tube:Ultra high quality blended rubber tube:3/8'' thick red tube.

Temperature:-40°F to+180°F.(-40°C to +82°C )

Nom.I.D		Nom.O.D		Vacuum		Bend Radius		W.p		Weight
(inch)	(mm)	(inch)	(mm)	(inch)	(mm)	(inch)	(mm)	(psi)	(mpa)	(lbs/ft)	(kg/m)
3''	76	4.49''	114.05	30''	762.00	14.00''	355.60	150	1.03	4.55	6.72
4''	102	5.27''	129.16	30''	762.00	18.00''	457.20	150	1.03	5.23	7.72
5''	127	6.45''	163.83	30''	762.00	24.00''	609.60	150	1.03	6.55	9.67
6''	152	7.48''	190.00	30''	762.00	28.00''	711.20	150	1.03	8.90	13.14
8''	203	9.53''	242.06	30''	762.00	48.00''	1219.20	150	1.03	13.24	19.55
10''	254	11.49''	291.85	30''	762.00	60.00''	1524.00	150	1.03	15.07	22.25
12''	304	13.74''	349.00	30''	762.00	90.00''	2286.00	150	1.03	21.77	32.14

Concrete Pumping Hose

High pressure hose designed to handle the pumping of concrete, plaster or grout mixture. All purpose cover provides excellent flexibility and wear resistance to abrasive slurries.

Construction:

Tube: Abrasion resistant static dissipating SBR

Reinforcement: 4 plies polyester tire cord

Cover: Black EPDM/SBR

Temperature: -20°F to +160°F(-28°C to +71°C)

ID		NOM. OD		MAX. WP		BEND RADIUS		WEIGHT
in.	mm.	in.	mm.	psi	Mpa	in.	mm.	lb./ft.	kg./m.
2	50.8	3.01	76.4	1233	8.5	9	275	2.75	4.10
2-1/2	63.5	3.50	88.9	1233	8.5	12	300	3.28	4.92
3	76.2	3.98	101.3	1233	8.5	14	350	3.80	5.65
4	101.6	5.02	127.4	1233	8.5	16	400	4.90	7.29
5	127.0	6.00	152.5	1233	8.5	20	500	5.98	8.90
6	152	7.25	184	1233	85	25	627	9.15	13.50

Note: Working Pressure 800PSI is available, or others could be customed.

MUD SUCTION HOSE

Flexible connection between slush pumping and mud to absorb vibration during rotary well drilling.

Wire helix design provides full vacuum capabilities.

Cover is oil, cut ,stuff and ozone resistant.

Tube: Specially compounded Nitrile.

Reinforcement: High strength tire cord with steel wire helix.

Cover: Oil resistant synthetic rubber.

Temperature: -40°F to+180°F.(-40°C to +82°C )

I.D		0.D		BEND RADIUS		WORKING PRESSURE PSI		WEIGHT LB/FT		VACUUM
(in)	(mm)	(In)	(mm)	(in)	(mm)	(psi)	(bar)	(lb/ft)	(kg/m)	VACUUM
4	101.6	5	127	24	609.6	100	6.90	4.70	3.16	FULL
6	152.4	7 1/8	181	36	914.4	100	6.90	8.50	5.71	FULL
8	203.2	9 1/4	235	48	1219.2	100	6.90	12.80	8.60	FULL
10	254	11 3/8	289	60	1524	100	6.90	19.50	13.10	FULL
12	304.8	13 3/8	340	72	1829	100	6.90	24.80	16.66	FULL

DRY CEMENT DISCHARGING HOSE -1/8” SBR TUBE

low pressure material transfer hose designed for discharge service of dry cement and powered abrasive materials.

Lightweight construction provides superior flexibility without sacrificing quality.

Premium grade cover resists cuts,scuff,and ozone attack .

Tube: 1/8” Extruded SBR.

Reinforcement: Synthetic, High tensile textile

Cover: Black SBR

Temperature:-40°F to + 150°F.(-40°C to +66°C)

Coupling: Hammer Union, Tank Union, etc. Hose assembly is electrically continuous unless otherwise specified by customer.

I.D		0.D		REINFORCEMENT	WORKING PRESSURE PSI		WEIGHT LB/FT
(in)	(mm)	(In)	(mm)	REINFORCEMENT	(psi)	(bar)	(lb/ft)	(kg/m)
4	101.6	4 1/2	114.3	2piles	65	4.48	1.49	1.00
4 1/2	114.3	5	127	2piles	65	4.48	1.67	1.12
5	127152.4	5 1/2	139.7	2piles	65	4.48	1.84	1.24
6		6 1/2	165.1	2piles	65	4.48	2.24	1.50

MUD SUCTION HOSE

Flexible connection between slush pumping and mud to absorb vibration during rotary well drilling.

Wire helix design provides full vacuum capabilities.

Cover is oil, cut ,stuff and ozone resistant.

Tube: Specially compounded Nitrile.

Reinforcement: High strength tire cord with steel wire helix.

Cover: Oil resistant synthetic rubber.

Temperature: -40°F to+180°F.(-40°C to +82°C )

I.D		0.D		BEND RADIUS		WORKING PRESSURE PSI		WEIGHT LB/FT		VACUUM
(in)	(mm)	(In)	(mm)	(in)	(mm)	(psi)	(bar)	(lb/ft)	(kg/m)	VACUUM
4	101.6	5	127	24	609.6	100	6.90	4.70	3.16	FULL
6	152.4	7 1/8	181	36	914.4	100	6.90	8.50	5.71	FULL
8	203.2	9 1/4	235	48	1219.2	100	6.90	12.80	8.60	FULL
10	254	11 3/8	289	60	1524	100	6.90	19.50	13.10	FULL
12	304.8	13 3/8	340	72	1829	100	6.90	24.80	16.66	FULL

End Fitting Options

Dock Hose 225PSI

APPLICATION:

CONSTRUCTION:

Tube: Nitrile synthetic rubber for up to 50% aromatics.

Cover: Black synthetic cover, corrugated, wrapped finish

Reinforcement: Spiral-plied heavy-duty synthetic fabric with double wire helix

Temperature: -25°F to 200°F (-32°C to 93°C)

COUPLING

ID		OD		MAX. WP		BEND RADIUS		VACUUM HG		WEIGHT
in.	mm.	in.	mm.	psi	Mpa	in.	mm.	in.	mm.	lb./ft.	kg./m.
3	76.2	3.89	98.8	225	1.55	11	279	29	737	3.28	4.88
4	101.6	5.29	134.4	225	1.55	15	381	29	737	6.30	9.38
6	152.4	7.34	186.4	225	1.55	22	559	29	737	9.50	14.14
8	203.2	9.43	239.5	225	1.55	30	762	29	737	13.81	20.55
10	254.0	11.63	295.4	225	1.55	40	1016	29	737	20.49	30.49
12	304.8	13.72	348.5	225	1.55	60	1524	29	737	25.13	37.40

Note: Working pressure 300PSI is available
