CE&ISO 280-630mm PE Water Supply Pipe Production Line
- SHANGHAI
- T/T D/P D/A
You May Like
Product Details
| Condition | New | Application | Other, Pipe, supply and drain pipe | |
| Plastic Processed | PE | Screw Design | Single-screw | |
| Automatic Grade | FULL AUTOMATIC | Place of Origin | Jiangsu, China | |
| Brand Name | CHICHENG | Model Number | SJSZ | |
| Voltage | 220V/380V/415V | Power(W) | According to the model | |
| Dimension(L*W*H) | According to the model | Weight | According to the model | |
| Certification | CE&ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
PE Water Supply Pipe Production Line1.280-630mm pipe size
2.2 sets 90mm extruders
3.SIEMENS motor&ABB inverter
4.CE&ISO
CE&ISO 280-630mm PE Water Supply Pipe Production Line
The System configuration of PE Water Supply Pipe Production Line
(a) Feeding machine
(b) Conical single-screw extruder
(c) Mould
(d) Vacuum Calibrating tank
(e) Hauling off machine
(f) Printing machine
(g) Pipe cutting machine
(h) Pipe pile-up frame
(i) Auxiliary machine such as feeding, belling and crushing machine.
Technical Date of PE Water Supply Pipe Production Line
| Main Eetruder | 45/33 | 75/33 | 60/33 | 75/33 | 990/33 | 90/33 | 120/33 | 120/33 | 150/33 | 150/33 | 150/33 |
| Pipe Diameter | 16-63 | 16-63 | 32-125 | 75-250 | 110-450 | 160-500 | 160-500 | 250-630 | 315-800 | 450-1000 | 630-1200 |
| Die Head | Single Outlet | Double Outlet | Single Outlet | ||||||||
| Down-stream Equipment | LG63 | SLG63 | LG125 | LG250 | LG450 | LG500 | LG500 | LG630 | LG800 | LG1000 | LG1200 |
| Total Power | 70 | 125 | 150 | 230 | 380 | 380 | 550 | 550 | 800 | 800 | 1000 |
Please feel free to contact us for more information. Additionally, it is worth noting that, it will be more advantageous if you told the diameter and more details of the pipes you are going to produce when sending your messages.
Advantages of PE Water Supply Pipe Production Line
1. Excellent in chemical corrosion, no rust;
2. With self extinguishing and flame retardant;
3. Excellent in anti aging, can be used 20years to 50 years between the temperature from subzero 15 to 60 degrees Celsius;
4. Wall is smooth, inner wall surface tension, it is difficult to form scale, the fluid transport capacity of 43.7% higher than the cast iron pipe;
5. The weight is light, easy to flaring, bonding, bending, welding, pipe installation workload is only 1 / 2 to the steel pipes, low labor intensity, short duration;
6. Good electrical properties of resistance, volume resistance of 1 to 3 x 105Ω.cm, breakdown voltage 23 to 2kv/mm;
7. The toughness of PE pipe is low, linear expansion coefficient is high, operating temperature range is narrow.
Main Applications
1. Water supply and drainage pipelines in building;
2. Rainwater drainage pipelines in building;
3. Electrical wiring pipe in building;
4. Air conditioning condensate water systems.
If you want more information, please contact us, thanks!
Our company is near Shanghai ,about 130km. Welcome to our factory anytime!
