CE Approved High Quality Pvc Pipe Belling Machine

CE Approved High Quality Pvc Pipe Belling Machine thumbnail-1
CE Approved High Quality Pvc Pipe Belling Machine photo-1
US$ 11,550 - 32,570 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Plastic Pipe
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Suzhou New Chicheng Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Product Type Plastic Pipe
Place of Origin Jiangsu, China
Brand Name CHICHENG
Model Number DY
Voltage 380V or As per request
Certification CE

Specifications

pvc pipe belling machine
1.Suitble for PVC pipe
2.Belling range 40-200mm
3.Steady performance
4.SGS,CE,ISO9001:2008

pvc pipe belling machine



1.For rectangular belling of PP,PP-R,PVC pipe etc.

2.It can bell J-type which called torque.

3.Belling range 40-200mm,voltage AC380V,50HZ;total power 18 kw,and total weight is 2500kg.

4.It both may be used with the plastic pipe production line and may be used with single machine.

5.Highly automated, performance steady and reliable ,and easy to operate.

6.Good adaptability of the craft,smooth and round belling,without abrasion,and belling size consistent and in good condition.



Main Technical Parameter

Central height

900-1000mm

900-1000mm

Pipe diameter specification

20-63mm

75-250mm

Max.length

8000mm

8000mm

Outline dimension

7656*1410*1900

8466*2901*2499

Displacement

500mm

900mm

Total power

32kw

50kw

Power of heating furnace(outside)

15kw

16.8kw

Power of heating furnace(inside)

3kw

5kw

Working pressure of hydraulic system

1.5-3.5mpa

1.5-5.5mpa

press pressure

0.6mpa

0.7mpa

Total weight

2800kg

5500kg







                CE approved high quality pvc pipe belling machine

                                                                    pvc   pipe   belling   machine











                                              Pipe samples                                                                               Belling mould
