Help Centerul Approved Emt 90 Degree Elbow
Related Products
-
Aluminum Electrical Pipes ElbowUS$ 0.65 - 96.34MOQ: 1 Piece -
Aluminum Conduit ElbowsUS$ 0.68 - 96.34MOQ: 1 Piece
-
Bend UL Listed Aluminum ElbowUS$ 0.69 - 96.35MOQ: 1 Piece
-
ul Rigid Aluminum Electrical Conduit ElbowsUS$ 0.76 - 96.24MOQ: 1 Piece
-
Rigid Aluminum 90 Degree Elbow BendUS$ 0.69 - 96.48MOQ: 1 Piece
Qinhuangdao Haimei Aluminum Co.,Ltd. (Haimei) specializes in manufacturing Aluminum products including Rigid Conduits, Elbows, Couplings and Nipples. All the products have been listed by UL and cUL (File No.: E310429) .
The deep knowledge and extensive experience of our engineering team in the field of metal processing have made Haimei's aluminum products the best in the world in terms of cost and quality. Our products are widely recognized by customers from North America, Europe, Asia and Africa, and were utilized in various projects such as power plant, water treatment facility, and paper mills. All of our customers have benefited from and satisfied with Haimei's low-cost and high-quality aluminum products. We received NONE complaint in the past six years.
Haimei is looking forward to fulfilling your need and creating win-win partnership.
Only Haimei Rigid Aluminum Conduit Offers 2 Ways to Save on Every Job
1.Lower Upfront Material Cost
| Percent Material Savings for Aluminum vs Galvanized |
size |
%Savings |
1/2” |
15% |
3/4” |
8% |
1" |
12% |
1 1/4” |
14% |
1 1/2” |
9% |
2" |
9% |
2 1/2” |
21% |
3" |
15% |
3 1/2” |
12% |
4" |
11% |
5" |
38% |
6" |
44% |
2.Less Installation Labor
| Persent Installation Labor Savings for Aluminum vs Galvanized |
| Size | Laid in Trench | 12"ceiling | 16"ceiling | 20"ceiling |
| 1 1/4" | 34.9% | 32.6% | 32.2% | 35.3% |
| 1 1/2" | 46.9% | 48.1% | 47.7% | 46.9% |
| 2" | 59.7% | 57.1% | 55.3% | 57.1% |
| 2 1/2" | 59.1% | 58.2% | 59.1% | 57.1% |
| 3" | 57.1% | 58.1% | 57.1% | 57.6% |
| 3 1/2" | 72.4% | 71.2% | 58.2% | 57.9% |
| 4" | 73.1% | 71.5% | 71.4% | 70.2% |
| 5" | 72.4% | 70.8% | 70.0% | 71.4% |
| 6" | 71.4% | 71.0% | 70.3% | 70.0% |
| Trade Size | Approxinate Weight | Nominal Diameter | |||||||
| Desingnator | per100Ft(30.5) | A | B | C | |||||
| U.S. | Metric | Ib. | Kg. | in. | mm. | in. | mm. | in. | mm. |
| 1/2 | 16 | 26 | 11.7 | 4.00 | 101.6 | 6.50 | 165.1 | 2.50 | 63.5 |
| 3/4 | 21 | 37 | 16.7 | 4.50 | 114.3 | 7.25 | 184.2 | 2.75 | 69.9 |
| 1 | 27 | 63 | 28.7 | 5.75 | 146.1 | 8.375 | 212.7 | 2.875 | 73.0 |
| 1-1/4 | 35 | 103 | 46.7 | 7.25 | 184.2 | 10.25 | 260.6 | 3.00 | 76.2 |
| 1-1/2 | 41 | 143 | 65.0 | 8.25 | 209.6 | 11.875 | 301.6 | 3.625 | 92.1 |
| 2 | 53 | 228 | 103.3 | 9.50 | 241.3 | 14.00 | 355.6 | 4.50 | 114.3 |
| 2-1/2 | 63 | 375 | 170.0 | 10.50 | 266.7 | 15.75 | 400.1 | 5.25 | 133.4 |
| 3 | 78 | 592 | 268.7 | 13.00 | 330.2 | 18.75 | 476.3 | 5.75 | 146.1 |
| 3-1/2 | 91 | 842 | 381.7 | 15.00 | 381.0 | 21.75 | 552.5 | 6.75 | 171.5 |
| 4 | 103 | 1084 | 491.7 | 16.00 | 406.4 | 23.00 | 584.2 | 7.00 | 177.8 |
| 5 | 129 | 2331 | 1058.0 | 24.00 | 609.6 | 36.00 | 914.4 | 11.00 | 279.4 |
| 6 | 155 | 3721 | 1688.0 | 30.00 | 762.0 | 42.50 | 1079.5 | 12.50 | 317.5 |
Professional |
with 7 years profesional manufacturing experience in aluminum products |
Profesinal production line,well -trained workers,strictQC standard | |
Main market |
Our products have shipped around the world |
|
North America , South America , North America, Eastern Europe , Africa , Oceania , Western Europe , Eastern Asia , Mid East | |
Service |
We have good and professional team |
We accept any drawings or your samples to develop new product | |
Any small problems will be solved at the most prompt time | |
We always offer relateive technical support,,quick response,all your inquire will replied within 24 hours | |
Certificate |
UL Certificate |
General Headquarters:
Post Address:No.158 Wenhua Road Haigang District Qinhuangdao Hebei Province,China
Factory Address:Changli Gold Coast,Qinhuangdao,Hebei
Telephone No: +86-335-5948600
Fax No:+86-335-3028323
Calling after Working Time: +86-13933651027 (Cinderella Liu)
