4ch h .264 Full DI DVR Kit

4ch h .264 Full DI DVR Kit thumbnail-1
4ch h .264 Full DI DVR Kit photo-1
US$ 95 - 98 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Antai
Model Number:
4ch DVR KIT
Contact Supplier Request Quote Chat Now
Antaivision Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Antai
Model Number 4ch DVR KIT

Specifications

1x 4 channel H.264 DVR
4x CMOS 700TVL Camera
4x 18m BNC to BNC Cable
1x Power Supply Adaptor
1x 1 to 4 Power Split


Product Description

4 Channel H.264 DVR Kit
-Model:AT-H3704TU-S+CMOS 700TVL(1090+8510)
-With 4 pcs CMOS 700TVL cameras and 4 pcs 18m cables
-Night vision up to 50ft(15m)with weatherproof IP65
-H.264 Compression & Virus free Linux O/S
-Support mobile phone live view & Email Alarm
-Real hexaplex operation -simultaneous record,playback,mobile phone live view,backup,control & remote access.
-Support full D1 real-time record (for 8304XA-NS)
-Hi-speed backup/upgrade/record via USB2.0

AT-H3704TU-S

Video output 1ch BNC(1.0Vp-p,75Ω), 1ch VGA , 1ch HDMI
Audio input 4ch RCA  (200-2800mV,30KΩ)
Audio output 1ch RCA (200-3000mV,5KΩ)
Alarm input 4ch (default not supporting,but can order )
Alarm output 1ch (default not supporting,but can order )
Network port 1*RJ45 10/100 Base-T self-adaptive Ethernet port
PTZ control 1*RS485 port, Support more than 5 kinds protocols.
USB port 2* USB 2.0 port
HDD port 1* SATA HDD interface,(1 HDD capacity up to 2TB)
Wireless Port 3G (extended by USB)
User level Admin
User right Users can set different permissions (How to use please refer to the manual book)
Password protection YES
Remote Independent Operation YES
Download records YES
Remote Event Trigger Recording YES
CMS CMS Software for multiple DVR (up to 255 DVR simultaneously)
Browser Internetie32-bit,360,Sogou,Google, Mozilla Firefox
Live Audio YES
On-line user Max.10
Mobile Surveillance YES (Supporting iPad, iPhone,Android;iPad, iPhone, Andriod remote playback function  )
Network Protocol DHCP/ADSL,PPPOE, SMTP,TCP / IP,DDNS,Wireless dial,WIFI,P2P
Motion detection FTP/YES
Event Notification  E-Mail
Pre-alarm Recording YES
Video loss Video loss notification
Buzzer No
IR remote controller Remotely control DVR and PTZ cameras via IR transmitter (IR receiver built-in)
Remote  control Yes
Cooling fan NO
Tour YES
Power Source (±10%) DC 12V / 2A
Power Consumption (±10%) <10W(without HDD)
Operating Temperature 0°C ~ +55°C
Dimensions (mm) ** 325mm(L)* 245mm(W)* 52mm(H)
System Recovery System auto recovery after power failure
Net Weight 0.9kg±0.1kg
Carton Box Size 5units packaging:358mm(L)* 83mm(W)* 270mm(H);        10units packaging:325mm(L)* 80mm(W)*255mm(H) ;
Package Size  5units packaging:440mm(L)* 375mm(W)*285mm(H) ;       10units packaging:415mm(L)* 335mm(W)*525mm(H) ;
Gross Weight 5units packaging:7.5kg±0.5kg;       10units packaging:14.0kg±0.5kg;

factory picture

4ch h .264 full DI DVR kit


Packaging & Shipping



Exhibition

4ch h .264 full DI DVR kit

Service

If you want to learn more and get latest price pls add my trademanager or send inquiry to me, I will be happy to service with you !



Serve every client with hearable smile.Welcome to Inquiry



Welcome to Ask Any Question



Welcome to Visit Our Factory



Antai Looks Forward to Serving You !!!
