US$ 110 - 112
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ANTAI
Model Number:
DVR-H4804AW
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
ANTAI
Model Number
DVR-H4804AW
Specifications
16CH 960H Real Time Recording / 8CH 960H Playback,16ch Video in / 1ch Video out, 2 x HDD,16ch Audio in / 1ch out, 8ch Alarm i| Operation interface | 16 bit real color GUI interface support mouse operation | ||
| Multilingual Language | YES, 28 kinds of language | ||
| Display screen | 1/4/8/9/16 Screen | 1/4/8/9/16/24 Screen | 1/4/8/9/16/24/32 Screen |
| Video Standard | PAL(625 lines, 50fps); NTSC(525lines, 60fps) | ||
| Image encode | H.264(Main Profile); JPEG Snapshot | ||
| Monitor quality | Monitor:D1; VGA & HDMI: (1920*1080,1280*720,1440*900,1280*1024,1024*768) | ||
| Playback quality | 960H/D1/HD1/CIF | D1/HD1/CIF | |
| Encode capability | 16ch 960H/D1 real-time | 8ch D1 real-time+16ch CIF real-time | 8ch D1 real-time+24ch CIF real-time |
| Decode capability | 960H mode:8ch 960H real-time D1 mode :16ch D1 real-time | 8ch D1 real-time+8ch CIF real-time | 8ch D1 real-time+8ch CIF real-time |
| Multi-Input (ONVIF 2.3) | Analogue: 16 *960H/16*D1 | Analogue: 8*D1+16*CIF | Analogue: 8*D1+24*CIF |
| Analogue+ Network HD: 8*D1+16*D1/8*D1+8*720P/8*D1+(2*1080P+2*720P)/4*D1+20*D1;/4*D1+(2*1080P+10*D1)/4*D1+(1*1080P+1*720P+10*960H); Network HD: 24* D1/20*960H/4*1080P/1*1080P+8*720P/2*1080P+4*720P+4*960H | Network HD: 24* D1/20*960H/4*1080P/1*1080P+8*720P/2*1080P+4*720P+4*960H | ||
| Audio compression | G.711A | ||
| Two-way Communication | YES | ||
| Record mode | Manual, alarm, motion detection, timing | ||
| Snapshot | NO | ||
| Local playback | 960H mode:8*960H@25fps D1 mode:16*D1@25fps | 16ch playback(8*D1@25fps+8*CIF@25fps) | |
| Video search | Time, date, event, channel search | ||
| Space Usage | Video CIF:4~5G/day*channel, D1:16~20G/day *channel,960H:9~42G/day*channel, 720P:10G~42G/day*channel,1080P:20G~80G/day*channel,Audio 691.2M/day *channel | ||
| Video storage | Local Hard Disk, Network | ||
| Back up mode | Network backup, USB portable HDD, USB DVD-RW | ||
| Video input | 16ch BNC(1.0Vp-p,75Ω) | 24ch BNC(1.0Vp-p,75Ω) | 32ch BNC(1.0Vp-p,75Ω) |
| Video output | 2 ch BNC(1.0Vp-p,75Ω), 1ch VGA,1ch HDMI | ||
| Loop Output | 16ch BNC(1.0Vp-p,75Ω) | NO | |
| Audio input | 16ch RCA (200-2800mV,30KΩ) | ||
| Audio output | 1ch RCA(200-3000mV,5KΩ) /1ch HDMI audio output | ||
| Alarm input | 16ch | ||
| Alarm output | 4ch | ||
| Network port | 1*RJ45 10/100 Base-T self-adaptive Ethernet port | ||
| PTZ control | 1*RS485 port, Support more than 20 kinds protocols. | ||
| USB port | Support USB 2.0 port | ||
| HDD port | Accommodates 4 SATA HDDs (1 HDD capacity up to 3TB) | ||
| Wireless Port | 3G & WIFI ( Extented by USB) | ||
| User level | Admin / User | ||
| User right | Users can set different permissions (How to use please refer to the manual book) | ||
| Password protection | YES | ||
| Remote Independent Operation | YES | ||
| Download records | YES | ||
| Remote Event Trigger Recording | YES | ||
| CMS | CMS Software for multiple DVR (up to 255 DVR simultaneously) | ||
| Browser | Internet Explorer, Mozilla Firefox, Google Chrome, Safari | ||
| Live Audio | YES | ||
| On-line user | Max. 10 | ||
| Mobile Surveillance | YES (Support iPad, iPhone, BlackBerry, Windows Mobile, Symbian & Android;iPad, iPhone, Andriod have remote playback function) | ||
| Network Protocol | DHCP,PPPOE,NTP,Email,IP Authority,DDNS,FTP,ARSP,Alarm Center,Wireless Dialing,Mobile Monitor,UPNP,Wifi,RTSP,Cloud Service | ||
| Motion detection | 16 × 12 grids per channel;6 adjustable parameters for accurate detection(for local analog channel only) | ||
| Event Notification | FTP / E-Mail | ||
| Pre-alarm Recording | YES | ||
| Video loss | Video loss notification | ||
| Buzzer | YES | ||
| IR remote controller | Remotely control DVR and PTZ cameras via IR transmitter (IR receiver built-in) | ||
| Remote control | YES | ||
| Cooling fan | YES | ||
| Tour | YES | ||
| Power Source (±10%) | DC 12V / 6A | ||
| Power Consumption (±10%) | <18W (without HDD) | ||
| Operating Temperature | 0°C ~ +55°C | ||
| Dimensions (mm) ** | 440mm(L)* 445mm(W)* 90mm(H) | ||
| System Recovery | System auto recovery after power failure | ||
| Net Weight | 6.0kg±0.1kg | ||
| Carton Box Size | 510mm(L)* 490mm(W)* 180mm(H) | ||
| Package Size | 528mm(L)* 508mm(W)* 390mm(H) | ||
| Gross Weight | 16.5kg±0.5kg | ||
