Home > Instruments & Meters > Test Instrument > Test Machine > Digital Concrete Test Hammer

Digital Concrete Test Hammer

Name: Digital Concrete Test Hammer
Brand: APEX
SKU: 115267633
Availability: InStock

Digital Concrete Test Hammer thumbnail-1

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

APEX

Model Number:

LKK422

Contact Supplier Request Quote Chat Now

Zhengzhou Prominent Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name APEX

Model Number LKK422

Power Other, Electronic, DC 3.6 ~ 4.2V or AC 100 ~ 240V

Usage Auto Testing Machine

Specifications

Concrete Test Hammer for nondestructive testing of concrete structural engineering ordinary concrete compressive strength.

LKK422 Digital Concrete Test Hammer Introduction:

Rebound system is equipped with specialized sensor life of more than 20 million times, ranking the leading domestic. Host system with rich peripheral resources that can be inserted into a pocket or waist, but also single-handed operation, not only for ordinary field operations, such as high-altitude climbing is more suitable for complex situations job.
Digital Concrete Test Hammer is mainly used for nondestructive testing of concrete structural engineering ordinary concrete compressive strength.

LKK422 Digital Concrete Test Hammer Main Feature:

Powerful:
               Host system professionally designed compact (113mm × 75mm × 27mm), can be placed in your pocket;
               International initiative U disk storage, unlimited storage capacity to meet a large number of engineering testing;
               Field print, view the raw data resilience, easy to save on file;
               Unique voice function, broadcast rebound value (or earphone), suitable for noisy environments;
               Can be used with any ordinary hammer mating, installation, calibration, maintenance convenient and reliable;
               Rechargeable lithium battery, external machine machine double charging capabilities to meet the needs of the field;
               Built more than strength curve for rebound method, ultrasonic synthesis methods to detect concrete compressive strength;
Operation is simple:
               The commonly used parameter is set to the default value, usually after boot to the test, convenient and fast;
               If the test conditions are the same number of members simply set a parameter, an automatically transferred to the next component after component testing is complete;
               Automatically records the date and time of detection, the rebound value, the scene point of view, the test surface, pumping, carbonation and other parameters amendments;
               You can set the normal range rebound values, and outliers alarm;
A host can be equipped with multiple warheads machinery back to ensure continuous testing work;
Powerful professional analysis software based on the relevant compliant design can be directly generated test report.

LKK422 Digital Concrete Test Hammer Main Specification:

Strength Measurement range: 10 ~ 60MPa;
Nominal kinetic energy: 2.207J;
Shells hit extension spring stiffness: 7.84N / cm;
Indication consistency error: ≤ ± 1 (poor mechanical Hammer pointer readings and instrument readings screen);
Steel anvil calibration rebound value: 80 ± 2;
Power: DC 3.6 ~ 4.2V or AC 100 ~ 240V;
Volume: Host (113mm × 75mm × 27mm), Hammer (φ60mm × 280mm)
Weight: Host 0.2kg, Hammer 1.0kg.

Packaging & Shipping

Compression wood packaging, air express

Our Services

Good method on using and operating lab equipment can greatly improving the testing accurate, improve the product quality and lengthen the service life of your instrument. This can help engineer to complete the testing.

APEX provide training service for equipment using and for the collective industry knowledge. Our aim is to spread complete laboratory knowledge, train common users to be professional operator.
