China waste tire recycling rubber powder machines
1. Working processing
Cut off tyre steel bead----cut tyre body into strips ----cut the strips into 50x50mm-----crush into 10-30 mesh-----separate steel wire------separate fiber----pure rubber powder 30-120mesh
2.Technical parameters
1.Ring cutter
Item |
Specification |
Motor power |
5.5 |
Speed of main screw |
46.8 r/min |
MAX Diameter of tyre |
1200mm |
Dimension |
1100*900*1700mm |
2.Loop machine
Item |
Specification |
Motor power |
15 KW |
Linear speed of front roller |
15.5 m/min |
Ratio of speed |
1.1 |
Dimension |
1520*1150*12101 |
Purpose:To Separate the steel ring from the rubber after 1 step. | |
3.strip cutter
Name |
Parameter |
Motor Power |
5.5 |
Disc Diameter |
380 |
Rotate Speed |
18.4 |
Dimension |
1290*870*1550 |
|
Purpose: To cut the old tyre intostrip
| |
4.block cutter
Item |
Specification |
motor power |
11kw |
Speed of main screw |
420 r/min |
Out diameter of cutter |
200mm |
Dimension |
1130*830*1100 |
Purpose: To Cut the strip into block | |
5.tyre crusher
Item |
XKP-560 |
Diameter of front roll(mm) |
560(smooth) |
Diameter of back roll(mm) |
510(groove) |
Working length(mm) |
800 |
Linear speed of front rollm/min) |
25.56 |
Ratio |
1:1.30 |
MAX gap(mm) |
15 |
Motor power(kw) |
75 |
Dimension (l*w*h)(mm) |
5070x2290x1980 |
Weight (kg) |
19000 |
6. Conveyor belt and Magnet separator and shaking screen
7.Fiber separator
