Help CenterXINFU The Bomb Calorimeter
Related Products
Specifications
Complete automatic calorimeter, automaticly stir, ignite, display status of process, alarm and print the result.GC106 Calorimeter is new developed model based on ZDHW-5 Calorimeter.
General Introduction of The Bomb Calorimeter
Calorimeter (Calorimeter), commonly known as the calorimeter, said kcal domestic instrument, the main measure calorific coal, straw and other solid, but also measurable heat oil and other liquids, mainly for thermal power, cement, coal, new energy, etc. fields.
Under High Pressure Oxygen Condition:
Put samples in hot-corrosion-resistant metal crucible.
Put this crucible in oxygen bomb and seal it.
Charge oxygen in the bomb until the pressure reach 3.0Mpa
Put oxygen bomb in and turn on the calorimeter, burn the sample.
The heat will pass to the water in cylinder.
Calorimeter can calculate the calorific value of samples according to measure the water temperature, cylinder and bomb.
Features of GC106
1, the use of advanced single-chip system, the instrument has automatic water, drainage, auto temperature, automatic mixing, automatic ignition, automatic printing and other functions, simple operation, long continuous measurement. 2, large-screen LCD display, Chinese menu prompt, simple and easy to operate. 3, with the experiment and converted high calorific functions. 4, automatic cooling calibration experiments, the use of ambient temperature requirements relaxed. 5, the automatic tracking the ambient temperature, the water temperature need not be measured outside the barrel.
Working Principle of The Bomb Calorimeter
Inner cylinder is also made of stainless steel, the cross section is oval. We special processed the surface to reduce the heat radiation and heat exchange. There is stirrer and thermometer hold designed on the top cover. Operator stick the temperature detector in the hole to test the temperature.
Standard Reference
ASTM E870 - 82(2013): Standard Test Methods for Analysis of Wood Fuel ASTM D7309 - 13: Standard Test Method for Determining Flammability Characteristics of Plastics and Other Solid Materials Using Microscale Combustion Calorimetry ISO 15971-2008: Natural gas - Measurement of properties - Calorific value and Wobbe index ISO 1928-2009: Solid mineral fuels - Determination of gross calorific value by the bomb calorimetric method and calculation of net calorific value ISO 9831-1998: Animal feeding stuffs, animal products, and faeces or urine - Determination of gross calorific value - Bomb calorimeter method
Main Specification
Heat Capacity 10500 J/K
Oxygen Bomb Capacity 300 ml
Oxygen Pressure 2.8~3.0 Mpa
Water Pressure 20 Mpa
Weight 2.5 kg
Dimension Φ86.2*181 mm
Outer Cylinder Capacity 17 L
Inner Cylinder Capacity 2.1 L
Display Range 0.000~65.000 ℃
Response Time <1 s
Resolution 0.001 ℃
Linearity <0.08% (Heating Rate 5℃)
Temp Accuracy 0.003℃ (Heating Rate 5℃)
Working Voltage AC:220±10%V
Operating RH <80%
Ignite Voltage AC:24V
Ignite Time 5 s
Total Weight 21.5 kg
