Double Chamber/ Double Room Double Control Silicone Curing Oven Vulcanization Oven
- Qingdao port
- T/T
You May Like
-
Made in China High Quality Silicone Rubber Oven Rubber Vulcanizing Oven
-
Chinese Supplier Silicone Post Curing Oven Silicone Rubber Secondary Vulcanization Oven
-
New Technology Silicone Oven Rubber Vulcanization Oven Silicone Curing Oven
-
High Quality With Good Price for Rubber Curing Oven
-
China New Technology Silicone Vulcanizing Oven
-
Cheaper Price for Silicone Post Vulcanization Oven
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | Zhihong | Model Number | DYG-E+E | |
| Voltage | 220V-460V | Power(W) | 21kwx2 | |
| Dimension(L*W*H) | 2180x3200x1450mm | Weight | 600kgx2 | |
| Certification | ISO9001 CE | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Double Chamber/ Double Room Double Control Silicone Curing oven
Introduction of the machine structure
This series of Silicone Curing oven is adopted double room double control design, equipped with 2sets stainless steel trolleys, per trolley including 5 to 12 layers trays, single room double door.
DYG series silicone secondary vulcanization oven special silicone rubber industry is the role of secondary vulcanization box of silicone rubber products in an environment of high temperature secondary sulfide, the sulfide in the process of sulfide has a pungent odor, using exhaust fan to exclude outside the workshop at the top of the strong, avoiding the accumulation, in the formation of crystals attached on the inner wall of the box, and the sealing strip.
Technical parameters for silicone curing oven with single room:
Model | voltage | Power KW | Working temperature scope(℃) | Uniform temperature (℃) | Motor powerW | Working room size (mm) | Overall size (mm) |
H×W×D | H×W×D | ||||||
DYG-A | 380V | 9 | room~300 | ±2.5 | 180 | 1000×800×800 | 1558×1410×1050 |
DYG-B | 380V | 12 | room~300 | ±2.5 | 370 | 1000×1000×1000 | 1780×1360×1250 |
DYG-C | 380V | 15 | room~300 | ±2.5 | 750 | 1200×1000×1200 | 1980×1360×1450 |
DYG-D | 380V | 18 | room~300 | ±2.5 | 750 | 1500×1200×1000 | 2180×1560×1250 |
DYG-E | 380V | 21 | room~300 | ±2.5 | 1100 | 1500×1200×1200 | 2180×1560×1450 |
DYG-F | 380V | 24 | room~300 | ±2.5 | 1100 | 1500×1200×1500 | 2180×1560×1750 |
Pictures for single room:
Technical parameters for silicone curing oven with double room:
Model | DYG-E+E | Working temperature: | Room~ 300℃ |
Voltage: | 380V/50HZ | Layers of tray | 12 |
Heater power: | 21x2 KW | Uniform temperature: | ±2.5℃ |
stainless steel trolley | 2 pcs | Distance between 2 trays | 100 mm |
stainless steel tray size | 1000x1100x30 | Total 12x2=24pcs | L×W×H(mm) |
Working room size | 1200×(1200*2)×1300 mm | D×W×H(mm) | |
Overall size | 1550×3020×2100 mm(control box located side) | D×W×H(mm) | |
Packing size | 1700×3200×2200 | D×W×H(mm) | |
Pictures for double room:
