High Gain External 3G Panel Hanging Antenna

Name: High Gain External 3G Panel Hanging Antenna
Brand: Yetnorson
Availability: InStock

FOB Price

US$ 7 - 7.5 / Piece

500 Pieces(Min. Order)

Port Shenzhen
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China		Brand Name	Yetnorson
Model Number	YNX-ZX-2.4G-Hanging-001

Packaging Details

One product with PE bag packaging and then one pruduct one Box

Product Description

High Gain External 3G Panel Hanging Antenna

Electrical Specifications of wall mount antenna
Frequency Range (MHz)	1710-2170MHz
Input Impendence (Ω)	50
V.S.W.R	≤1.2
Gain (dBi)	14dBi
F/B Ratio	≥15dB
Horizontal Beam width	60°-90°
Vertical Beam width	70°-70°
Polarization Type	Vertical
Power Capacity (w)	100
Mechanical Specifications wall mount antenna
Antenna Dimension	210mm180mm45mm
Connector	TNC-Female
Weight	0.6kg
Mounting Mast Diameter	Ø30~Ø50mm
Rated Wind Velocity	210Km/h
Operating Temperature	-40°C to+80°C
Radome Material	UV protected ABS
Radome Colour	White
Mounting way	on the wall or hold in the pole

Refund & Replacement

1. We can guarantee the product quality within one years .

2. If parts cannot work, we will return payment or replacement to you.

3. Any items must be returned in their original condition to qualify for a refund or replacement.

4. The buyer is responsible for all the shipping cost incurred.

Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation!!!

Company Profile

Shenzhen Yetnorson Technology Co., Ltd.

Shenzhen Yetnorson Technology Co.,Ltd is one of professional antenna maker, which focus on GSM/CDMA/PHS/3G/4G antenna, 2.4GHz (wi-fi, wlan)/3.5GHz (wimax)/5.8GHz/wi-fi amplifier communication antenna serial(including: all direction, yagi antennas ,3G parabolic antennas, panel antenna, indoor antenna like : ceiling mount antenna, Wall Mount Antenna, desk antenna, double polar, rubber, bandwide, card mount serial antenna. We also provide DVB-T/DMB-T/CMMB moving digital TV antenna, low frenquency antenna: 315MHz/433MHz wi-fi digital /wi-fi control /wi-fi wrote water meter/electricity meter antenna, GPS guide antenna, communicate parts, connector and so on. At present, Shenzhen Yetnorson Technology Co.,Lth.has developed more than 100 styles of antenna, with wi-fi internet, wi-fi electronic control, wi-fi end, wi-fi public telephone, wi-fi digital pass, wi-fi Satilla position, wi-fi Radio broadcasting communication field. We offer antennas with good quality and good price. And we are cooperating with several overseas clients from all over the world. Please support us. Thank you very much!
