Leading Manufacturer & Solution Provider of Mobile LED Advertising Vehicles
YEESO LED Truck With Stage, Ourdoor Advertising Truck, Road Show Truck:
Technical Details of YEESO LED Truck With Stage, Ourdoor Advertising Truck, Road Show Truck:
Brand | SCGC | External dimension | 12000mm×2535mm×2650mm |
Curb weight | 10000KG | Gross mass | 26000KG |
Hydraulic Lifting & Supporting System | |||
Hydraulic lifting system | Electric putt (Germany technology) Lifting height: 2000mm,afford 5T,synchronous error:1mm | Hydraulic supporting system | It can goes up 800mm,each afford 10T,its wind-proof level can reach to maximum level 8 when screen is lifted up |
Extreme Super Silent Generator Set | |||
External dimension | 1510mm×900mm×1060mm | Power | 16KW |
Power type | KIPOR | Number of cylinders | Water-cooled inline 4-cylinder |
Air displacement | 3.595L | Bore*stoke | 114mm×120mm |
LED screen | |||
Main Screen size | 4800mm×2400mm | Module size | 160mm(W) ×160mm(H) |
Chip | R:GUANGLEI; G,B:SILAN | Pixel pitch | 10mm |
Brightness | ≥6000cd/m² | Max power consumption | 1200W/m² |
Power consumption | Average: 600W/m² | Life span | 100,000hours |
Power Supply | |||
Input voltage | Three phases, five wirings,380V | Output voltage | 220V |
Electrical current | 50A | Power consumption | Average:0.5wh/m² |
Multi-Media Control System | |||
Industrial PC | Processor: Dual Core CPU; Display card: 512; Hard Disk:500G; CD-ROM: DVD; Internal storage:2G | Power amplifier | Unilateral power output:200W*2 |
Monitor | KVM 15-inch LCD display | Control system of LED screen | LINSN/ZHOGNQING (technology of point by point correction) |
Speakers | Max power consumption:200W×4 |
|
|
Outer Frame and Inner Decoration | |||
Cold rolled metal plate | 1.5mm | Surface car baking varnish | Pure white |
Inner decoration | Fire Retardant Board | Waterproof processing | Vehicle plastic irrigation processing |
Applications of YEESO LED Truck With Stage, Ourdoor Advertising Truck, Road Show Truck:
Press Release | News conferences, product launches, channel investment activities, press appearances , etc |
Activities Road Show | Promotions, public relations activities, product marketing, branding promotion, draft activities, live shows and other sales |
Live | Sporting events, live events, concerts, etc. |
Parade Display | Product buildings parade promotion, exhibitions, fairs, shows, etc |
Forum Lecture | forums, conferences and seminars |
Celebration &Ceremony | Real estate opening, anniversary celebration, the opening ceremony, festivals, ribbon-cutting ceremony, award ceremonies. |
Election | promotion for election, policy promotion |
Other Applications | Wedding live, auction, et |
