Specifications
1.Single girder grab crane2.Capacity: 3T, 5T,10T
3.Low noise & good condition
4.With top brand parts
5.Mid-duty class
Electric hoist type single girder overhead grab crane - LZ model single girder grab crane:
1. LZ model single girder grab crane is improved and designed on the basis of LD model single girder overhead crane.
2. This grab crane is characterized by more reasonable structure and higher strength steel as a whole, the main beam and end carriage are made by U-section steel plate.
3. This grab crane is used together with wire rope electric hoist and grab as a complete set.
4. This grab crane is medium duty class crane, the capacity from 3ton to 10 tons. The span from 7.5m to 31.5m, the working grade is A3/A4. Working temperature within -25 to +40 centigrade.
5. This grab crane is widely used in plants, warehouses to handle loose-packed material. It is prohibited to use the equipmenmt in the combustible, explosive to corrosives environment..
6. The box frame main beam of single girder overhead crane, the straight welds performed by automated robotics, the welder will perform welding on curved locations only, the welding type is carbon-dioxide arc welding:
7. The end carriages of single girder overhead crane, the crane wheels are finished heat treatment for long life, the noise of motors & speed reducers are very small:
8. The lifting mechanism(electric hoist) of single girder overhead crane, the gear boxe have hardened and ground helical gears for high efficiency, quite operation and high reliability:
9. The picture of grab:
10. The packing, transport & loading of single beam overhead crane:
