Digital temperature controller refrigerator EK-3030
EK-3030 Temperature Controller
General:
This controller is suitable for temperature control of the middle and low temperature cold storage.
It could measure, display and control temperature, with the function of temperature calibration, forced defrost and temperature over temperature alarm and sensor failure alarm, one key recovery of the factory default value, parameters preset and one key recovery. It adopts touch key design wit the key lock function
Dual-way sensor input: cabinet temperature sensor and defrost sensor
Three way control output: Refrigeration, defrost and fan
Features:
Six touch key design, quick parameter setting, easy operation
Multiple defrost control modes, more stable and energy saving, avoid cold storage swell.
Defrost cycle power off memory function
Construction contractor could preset a group of parameters, with one key recovery function
Three work modes:Refrigeration mode, heating mode and constant temperature mode
Technical parameters:
1) Measuring range:-40°C~99°C
2) Controlling range:-40°C~85°C;
3) Accuracy:-30°C~50°C,±1°C±0.5dig; others, ±2°C±0.5dig
4) Resolution:0.1°C / 1°C
5) Mounting size: 71mm*29mm
6) Power supply: 220±10%(VAC), 50/60Hz
7) Power consumption:<5W
8) Output capacity:
Refrigeration:10A/220VAC or 16A/220VAC, directlydrive a singlephase compressor 1HP
Defrost:10A/220VAC
Fan:10A/220VAC
One way buzzer alarm output
9) Work ambient temperature:-5°C~55°C;work ambient humidity:10%~90% non condensing
10) Storage temperature:-25°C~85°C
11) Senor type: NTC(10KΩ/25°C,B value 3435K)
12) Sensor length: 2M
