big spindle bore heavy duty machines
1.CK6180E1000mm chinese metal lathe Features
1. one piece casting machine bed, higher stability and longer 2-3 years service life.
2.three-gear variable speed.
3.heavier 300-600 kg machine bed than our domestic south machine supplier.
2.CK6180E big spindle bore heavy duty machines specification
| heavy duty machines | CK6180E 1000mm | |
| Capability | Max. swing dia. over bed | 800mm |
| Max. swing dia. over cross slide | 480mm | |
| Max. processing length | 1000mm | |
| Spindle | Spindle speed | first-gear speed 70-260r/min |
| second-gear speed 25-100r/min | ||
| third-gear speed 220-850r/min | ||
| Spindle speed grade | infinitely variable speeds | |
| Go-ball dia. of spindle | 100mm | |
| Spindle taper | 120 1:20 | |
| Spindle nose | C11 | |
| X/Z | X/Z position accuracy | 0.025/0.03mm |
| X/Z repeatability | 0.012/0.013mm | |
| Tool holder | Type | 4-position electric type |
| Tool tavel | 430/1200mm | |
| Tool bar section size | 30*30mm | |
| Main motor model No. | YVP180L-4-11KW | |
| Ball screw dia. and thread pitch | 3205*6310mm | |
| Rapid traverse speed | 4000/5000mm | |
| Work piece processing pocision accuracy | IT6-IT7 | |
| work piece surface rughness | 1.6 | |
| Tailstock | Tailstock sleeve dia. | 100mm |
| Tailstock sleeve strock | 250mm | |
| Dimension | 3700*1820*1780mm | |
| Net weight | 3600kg | |
3.Warranty for heavy duty machines
1. engineers are available to do oversea machinery service. In some countries, we have oversea
agent doing after-sale service in time and professionally.
2.24 hours heart to heart service on-line or mobile.
3. training in our factory and on-line are free of cost.
4. warranty is 12 months, small broken parts are free of cost to replace, spare parts are delivered
with machine for customer convenience.
5.We offer best agent price and distributer price.
4. Office building and work shops
