ck6180 cnc torno
1. ck6180 cnc torno specification
| ck6180 cnc torno | CK6180E 1000mm | |
| Capability | Max. swing dia. over bed | 800mm |
| Max. swing dia. over cross slide | 480mm | |
| Max. processing length | 1000mm | |
| Spindle | Spindle speed | first-gear speed 70-260r/min |
| second-gear speed 25-100r/min | ||
| third-gear speed 220-850r/min | ||
| Spindle speed grade | infinitely variable speeds | |
| Go-ball dia. of spindle | 100mm | |
| Spindle taper | 120 1:20 | |
| Spindle nose | C11 | |
| X/Z | X/Z position accuracy | 0.025/0.03mm |
| X/Z repeatability | 0.012/0.013mm | |
| Tool holder | Type | 4-position electric type |
| Tool tavel | 430/1200mm | |
| Tool bar section size | 30*30mm | |
| Main motor model No. | YVP180L-4-11KW | |
| Ball screw dia. and thread pitch | 3205*6310mm | |
| Rapid traverse speed | 4000/5000mm | |
| Work piece processing pocision accuracy | IT6-IT7 | |
| work piece surface rughness | 1.6 | |
| Tailstock | Tailstock sleeve dia. | 100mm |
| Tailstock sleeve strock | 250mm | |
| Dimension | 3700*1820*1780mm | |
| Net weight | 3600kg | |
2. ck6180 cnc torno features
guide width 600mm
higher stability one-piece machine bed
3 gear spindle speed, stepless in gear
higher rigidity pedestal
wider layer board
integrated automatic lubrication system
3. ck6180 cnc torno usage
This machine is suitable to process the middle and large size work piece in steel, cast iron, non-ferrous metal material. With the feature of big power and higher rigidity, this machine is applied to heavy-cut the inner circle, ex-circle, end surface and thread in both metric and English system, and could drill and bore holes.
4. ck6180 cnc torno standard accessories
GSK980TDC or Siemens 808d NC system
11kw inventer main motor
4 station electric turret
400mm manual chuck
manual tailstock
automatic integrated lubrication system
coolant system
lighten system
5. ck6180 cnc torno optional accessories
Fanuc 0I mate TD NC system
6 station or 8 station electric turret
steady rest
follow rest
11/15 kw servo motor
15 kw inverter motor
15" domestic thru-hole hydraulic chuck
15" Taiwan thru-hole hydraulic chuck
Full enclosed cover
