Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > CH6250C Herramientas

CH6250C Herramientas

Name: CH6250C Herramientas
Brand: PULUTE
SKU: 115202829
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Contact Supplier Request Quote Chat Now

Shandong Pulute Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Qingdao Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 500MM

Place of Origin China

Brand Name PULUTE

Model Number CH6250C

Voltage 380V

Power(W) 4KW or 5.5KW

Dimension(L*W*H) 288*115*165 cm

Weight 2150KG

Certification CE, ISO9001, ISO14001

After-sales Service Provided Engineers available to service machinery overseas

CH6250C herramientas

1. CH6250C herramientas specification

capacity	herramientas	bench lathe C6250C
	Swing over bed	500mm
	Swing over cross slide	330mm
	Max.swing over gap	660 mm
	Effective length of gap	200 mm
	Center Distance	750mm/ 1000mm/1500mm
	Bed Width	360 mm
head stock	Spindle hole	52 mm
	Spindle nose	ISO-C6
	Spindle taper	MT6#
	Spindle speed(Number)	(9steps)40-1400rpm
threads	Module threads range	11 kinds 0.25-3.5 mm/rev
	Metric threads range	18 kinds 0.5-14mm
	Inch threads range	27kinds 2-20inch
carriage	Max. Travel of top slide	95 mm
	Max. Travel of cross slide	230 mm
	Max. Size of tool shank	20*20 mm
tailstock	Dia.of tailstock sleeve	65mm
	Taper of tailstock sleeve	MT4
	Max.travel of tailstock	140mm
motor	Main drive motor	4KW or 5.5 KW
motor	Coolant pump motor	125W
Dimension	750mm C6236H	225115165cm
	1000mm C6236H	245115165cm
	1500 mm C6236H	288115165 cm
weight	750mm C6236H	1500/1900 kg
	1000mm C6236H	1600/2000kg
	1500 mm C6236H	1750/2150kg

2. CH6250C herramientas standard accessories

3. CH6250C herramientas optional accessories

4. CH6250C herramientas features

Bed rail is VHF hardening and precision grinding , higher rigidity and higher precision.
Head-stock gears are precision grind-ed, lower noise .
Threads turned are variety.
Electricity is very safety in performance, high reliability.
An electromagnetic valve optional could brake the lathe and improve lathe safety.

Bed is available for a variety of colors.

Click send now and get the more info. of our products.
