GPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking Systems

GPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking Systems photo-1
GPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking Systems photo-2
GPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking Systems photo-3
GPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking Systems photo-4
GPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking Systems photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Gps Tracker
Use:
Automotive
Screen Size:
Other, no screen
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Type Gps Tracker
Use Automotive
Screen Size Other, no screen
Function Other, tracking position, tracking history, cut off fuel, cut off power,
Place of Origin Guangdong, China
Brand Name eelink
Model Number GPT09
Warranty 1 Years

High quality magnetic waterproof level IP67 gps tracker for car with built in a big battery 14500mAh.Throw it to the bottom of the vehicle,paste it to the value assets, or to the container. so easy to track from now on.It’s internal battery canstandby for 3years,never waste time to charge it now, Military grade three anti-performance, waterproof to IP67! it’s a high SPY gps tracking device.Your best choice now!




In today’s fast-pace and high-tech market, your customers expect quality service delivered on time, every time. Delivery truck tracking systems provide tracking and reporting capabilities for service and delivery vehicles, helping you provide standout customer service – at a lower cost. When you know the “where” and “when” of your vehicles’ locations, you can better manage your services, inventory and employees for improved business operations. Track delivery trucks with ease!



  • Our vehicle tracking software offers asset allocation features, which allow you to locate the closest vehicle to a specific destination for faster pickups and deliveries.
  • GPS fleet tracking software and enhanced real-time reporting offers speed, location and heading of vehicles, so you can stay on top of your employees’ activity – reducing idle time and late arrivals.
  • GPS for service verhicles have been certified and tested by top carrier networks, which means that our systems work and keep your business in compliance.



Product Highlights:
1.Magnet+waterproof design;
2.GPS / LBS dual positioning;
3.Built in large high quality battery;
4.Support OTA upgrade firmware;
5.Easy sms tracker
6.FREE web based gps tracking platform and public hardware communication protocol;


Product Features
1 Supports quad bands, i.e. 850/900/1800/1900MHz, universal in the world.
2 Built-in 14500mAh Super high-capacity zero self-discharge lithium thionyl chloride batteries, can stand up to three years( Power on once per day)
3 Strong magnetic force,can be installed on iron absorption
4 Military grade three anti-performance, waterproof to IP67
5 GPS / LBS dual positioning, support A-GPS
6 Customize 6/12/24/48-hour work intervals in long standby mode
7 Switch to emergency mode to restore the real-time tracking mode
8 WEB platform, mobile APP, SMS remote setting mode, tracking devices
9 Support protocol, can be used in customer platform
10 OTA upgrade firmware.



Basic Specifications

Voltage

3.7 VDC

Work Current

<30 mA

Standby Current

<15 uA

GPS Accuracy

5-15m

GSM Accuracy

About 100m

GPS Frequency

1575MHz

GSM Frequency

850/900/1800/1900MHz

Hot/warm/cold Start

<3s,<15s,<60s

Battery Capacity

14500 mAh

Dimensions (mm)

87(L)X41.6(W)X 12(H)

Work Temperature

-20℃~70℃

Work Humidity

20%~80%RH

Net Weight

180g

IPR

IP67








Products Interface



GPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking SystemsGPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking SystemsGPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking SystemsGPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking SystemsGPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking SystemsGPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking Systems





  GPS TRACKING SYSTEM

GPT09 Magnetic GPS Trailer Tracking Systems, Equipment Tracking Systems







1) Geo-fence Alarm













Package



Packing List1 x GPS (5cm)
 1 x Power cable (100cm)
 1 x Microphone (150cm)
 1 x SOS button
 1 x English user manual
 1 x Chinese / English instruction manual



Office and Laboratory







Factory SMT Workshop













Factory Cable Assembly  Workshop











Company Certificate



Focusing on products that are truly superior and innovative, Eelink has been awarded China National Hi-tech Enterpriseand Software Enterpise, Certificate of Utility model Patent Certification, Eelink’s products have passed the international certification BV, SGS,D&B, Design Patent, CE, FCC, PAHs,CCC,etc.
