GPS For Shipments & Asset Tracking TK116

GPS For Shipments & Asset Tracking TK116 thumbnail-1
GPS For Shipments & Asset Tracking TK116 photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Gps Tracker
Use:
Automotive
Screen Size:
Other, no screen
Contact Supplier Request Quote Chat Now
Shenzhen Eelink Communication Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Gps Tracker
Use Automotive
Screen Size Other, no screen
Function Other, tracking position, tracking history, cut off fuel, cut off power
Place of Origin Guangdong, China
Brand Name eelink
Model Number TK116

Specifications

Track by SMS/GPRS
-SOS Alarm,Geo-fence Alarm
-External Power Cut Alarm
-Engine Cut, Low Battery Alarm

There are many business reasons for deploying a real-time gps tracking device on any shipment of goods from a vendor to a customer. From the vendor side, delivery of products can be extremely time sensitive. For example, shipping produce requires quick turnaround for a delivery and a gps tracking device provides a tight view on where the shipment is and what if any time adjustments need to be made to ensure the freshness and quality the customer is expecting.



Beyond a shipment that is time sensitive, with skyrocketing fuel prices, dispatch can now re-route deliveries to make the most of existing resources. Additionally, lost or stolen product can be greatly reduced by using the Global Tracking Group gps tracking software to identify the precise location of the shipment.



From the customer side, knowing the location and expected delivery of a shipment on a real-time basis will help with planning and resource requirements once the shipment has arrived.

.



Shenzhen Eelink is a manufacturer and exporter of GPS Trackers, Vehicle Tracking Devices, Personal Tracking device. We also offer mature GPS Tracking Solutions including vehicle tracking, personal security, and fleet management



Environment for use

1.Limited working temperature:-20°C~80°C

2.Storage temperature:-45°C~90°C
3.Humidity:<95%
4.Atmospheric pressure:86kPa~106kPa
5.Make sure the terminal is installed in rainproof
and snow-proof places.

6.Battery: 200MAh battery



Basic Specifications:

Voltage: 12VDC/24VDC
Standby : Current <3mA
Work current : <30mA
GPS positioning accuracy : 15m
GSM positioning accuracy : 100m
GPS Frequency : 1575MHz
GSM Frequency : 850/900/1800/1900MHz
Hot/warm/cold start time : <3s,<15s,<60s
Dimensions (mm) L*W*H : 79.5X38.5X10.5
Weight : 45g



Product Features
1.Supports quad bands, i.e. 850/900/1800/1900MHz, universal in the world.
2.Wide Input Voltage:6-36V DC.
3.Supports single positioning and feedbacks position via GPRS at setting times.
4.Supports vehicle positioning and tracking.
5.Supports ACC status checking and vehicle status notifying.
6.Use relay to remote control the vehicle..
7.Use SOS button for SOS call.
8.Use external MIC to monitor remotely



 Main function



Brand Eelink
Model VT06
Quantity 1 piece(s)
Color Black
Material ABS
Network GSM
Band 85090018001900 MHz
SIM Card Qty. one SIM
Emergency Phone Number Qty. 3
Tracking Information Method Monitoring and controlling platform
Power Supply DC 6~36V
GPS Chip SIRF
GPS Sensitivity -163 dB
GPS Channel 20
Position Accuracy 10 m
Altitude Limit 18000 m
Hot Start 3 seconds
Warm Start 15 seconds
Cold Start 60 seconds
SOS Yes
Geo-fence Yes
Vibrating Alerts Yes
Remote Monitoring Yes
Engine Cut Off Yes
Realtime Monitoring Yes
Track Playback Yes
ACC Anti-Theft Yes
Overspeed Alerts Yes
Low Battery Alerts Yes
GPS Blind Area Alarm Yes
Voice Call No
Waterproof Function Yes
Waterproof Rate Daily user water resistant
Working Temperature -35~75'C
Working Humidity 5%~95%
Manufacturer's Warranty 12 Months excluding physical damages (see specifications for terms and details)
Certification CE




GPS Shipments & Asset Tracking  Solutions

GPS For Shipments & Asset Tracking TK116



Detail picture



GPS For Shipments & Asset Tracking TK116

GPS For Shipments & Asset Tracking TK116GPS For Shipments & Asset Tracking TK116





GPS TRACKING SYSTEM



GPS For Shipments & Asset Tracking TK116







Package

Packing List 1 x GPS (5cm)
  1 x Power cable (100cm)
  1 x Microphone (150cm)
  1 x SOS button
  1 x English user manual
  1 x Chinese / English instruction manual





 GPS For Shipments & Asset Tracking TK116



Accessories



GPS For Shipments & Asset Tracking TK116



GPS For Shipments & Asset Tracking TK116





Office and Laboratory

GPS For Shipments & Asset Tracking TK116





Factory SMT Workshop

GPS For Shipments & Asset Tracking TK116





Factory Cable Assembly  Workshop



GPS For Shipments & Asset Tracking TK116





Company Certificate

Focusing on products that are truly superior and innovative, Eelink has been awarded China National Hi-tech Enterprise and Software Enterpise, Certificate of Utility model Patent Certification, Eelink’s products have passed the international certification BV, SGS,D&B, Design Patent, CE, FCC, PAHs,CCC,etc.
