Home > Electrical & Electronics > GPS > GPS Navigator > Vehicle Tracking Unit Consists of a Built-in GPS Receiver, GSM Modem and Battery for Back up During Failure of External Power

Vehicle Tracking Unit Consists of a Built-in GPS Receiver, GSM Modem and Battery for Back up During Failure of External Power

Vehicle Tracking Unit Consists of a Built-in GPS Receiver, GSM Modem and Battery for Back up During Failure of External Power thumbnail-1
Vehicle Tracking Unit Consists of a Built-in GPS Receiver, GSM Modem and Battery for Back up During Failure of External Power photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Gps Tracker
Use:
Automotive
Screen Size:
Other, no screen
Contact Supplier Request Quote Chat Now
Shenzhen Eelink Communication Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Gps Tracker
Use Automotive
Screen Size Other, no screen
Function Other, tracking position, tracking history, cut off fuel, cut off power
Place of Origin Guangdong, China
Brand Name eelink
Model Number VT06

Specifications

1.Logistics
2.Fleet management
3.Commercial Vehicle Monitoring
4.Delivery & Courier services

Vehicle Tracking Unit equipped with state of the art GPS receiver provides reliable and accurate navigation data. The unit enables the vehicle owners or third parties to track the location of a Truck, Ship, Container, Car or any object which is on the move.

All the communication with the user/server is handled by Quad-Band GSM/GPRS module which accurately delivers all the navigation date. The communication is either through Short Message Service (SMS) or GPRS network.

Application Areas

  • Logistics
  • Fleet management
  • Commercial Vehicle Monitoring
  • Delivery & Courier services
  • Public Transport Systems
  • Taxi Services
  • Emergency Vehicles and Security Vehicles

Environment for use



1,Limited working temperature:-20°C~80°C
2,Storage temperature:-45°C~90°C
3,Humidity:<95%
4,Atmospheric pressure:86kPa~106kPa
5,Make sure the terminal is installed in rainproof
and snow-proof places.

6.200MAh battery



Basic Specifications:
Voltage: 12VDC/24VDC
Standby : Current <3mA
Work current : <30mA
GPS positioning accuracy : 15m
GSM positioning accuracy : 100m
GPS Frequency : 1575MHz
GSM Frequency : 850/900/1800/1900MHz
Hot/warm/cold start time : <3s,<15s,<60s
Dimensions (mm) L*W*H : 79.5X38.5X10.5
Weight : 45 g



Product Features
1.Supports quad bands, i.e. 850/900/1800/1900MHz, universal in the world.
2.Wide Input Voltage:6-36V DC.
3.Supports single positioning and feedbacks position via GPRS at setting times.
4.Supports vehicle positioning and tracking.
5.Supports ACC status checking and vehicle status notifying.
6.Use relay to remote control the vehicle..
7.Use SOS button for SOS call.
8.Use external MIC to monitor remotely



 Main function

Brand Eelink
Model TK116
Quantity 1 piece(s)
Color Black
Material ABS
Network GSM
Band 85090018001900 MHz
SIM Card Qty. one SIM
Emergency Phone Number Qty. 3
Tracking Information Method Monitoring and controlling platform
Power Supply DC 6~36V
GPS Chip SIRF
GPS Sensitivity -163 dB
GPS Channel 20
Position Accuracy 10 m
Altitude Limit 18000 m
Hot Start 3 seconds
Warm Start 15 seconds
Cold Start 60 seconds
SOS Yes
Geo-fence Yes
Vibrating Alerts Yes
Remote Monitoring Yes
Engine Cut Off Yes
Realtime Monitoring Yes
Track Playback Yes
ACC Anti-Theft Yes
Overspeed Alerts Yes
Low Battery Alerts Yes
GPS Blind Area Alarm Yes
Voice Call No
Waterproof Function Yes
Waterproof Rate Daily user water resistant
Working Temperature -35~75'C
Working Humidity 5%~95%
Manufacturer's Warranty 12 Months excluding physical damages (see specifications for terms and details)
Certification CE
Packing List 1 x GPS (5cm)
  1 x Power cable (100cm)
  1 x Microphone (150cm)
  1 x SOS button
  1 x English user manual
  1 x Chinese / English instruction manual





GPS Vehicle Tracking solutions



 Vehicle Tracking Unit consists of a built-in GPS receiver, GSM modem and battery for back up during failure of external power







Detail picture

 Vehicle Tracking Unit consists of a built-in GPS receiver, GSM modem and battery for back up during failure of external powerVehicle Tracking Unit consists of a built-in GPS receiver, GSM modem and battery for back up during failure of external powerVehicle Tracking Unit consists of a built-in GPS receiver, GSM modem and battery for back up during failure of external power










GPS TRACKING SYSTEM



 Vehicle Tracking Unit consists of a built-in GPS receiver, GSM modem and battery for back up during failure of external powerVehicle Tracking Unit consists of a built-in GPS receiver, GSM modem and battery for back up during failure of external power







PACKAGE

Packing List 1 x GPS (5cm)
  1 x Power cable (100cm)
  1 x Microphone (150cm)
  1 x SOS button
  1 x English user manual
  1 x Chinese / English instruction manual





 Vehicle Tracking Unit consists of a built-in GPS receiver, GSM modem and battery for back up during failure of external power



  ACCESSORIES



Vehicle Tracking Unit consists of a built-in GPS receiver, GSM modem and battery for back up during failure of external power



Vehicle Tracking Unit consists of a built-in GPS receiver, GSM modem and battery for back up during failure of external power
