Truck Tracking Device, Track Your Truck via VT06

Truck Tracking Device, Track Your Truck via VT06 thumbnail-1
Truck Tracking Device, Track Your Truck via VT06 photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Gps Tracker
Use:
Automotive
Screen Size:
Other, no screen
Contact Supplier Request Quote Chat Now
Shenzhen Eelink Communication Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Gps Tracker
Use Automotive
Screen Size Other, no screen
Function Other, tracking position, tracking history, cut off fuel, cut off power
Place of Origin Guangdong, China
Brand Name eelink
Model Number VT06

Specifications

1.Reliable GPS Tracking for Trucks
2.Tracking via mobile phone
3.tracking from PC
4.logger hoistory replay

An advanced bus tracking system from Track Your Truck lets you know where your vehicles are, when they will arrive for pickup or delivery, and even how fast they are traveling. With detailed reporting capabilities, you can provide outstanding customer service and manage a better business all around. Eelink offers GPS tracking for trucks and buses that paves the way for efficiency, profitability, safety and security.

  • With Enterprise Data Services, you can have real-time tracking data flow to your in-house applications. Embed mapping of your vehicles on your website so customers can track their services online.
  • Premier, enhanced map data by Google Enterprise Maps span most of the U.S. and the world, with easy-to-use features and a familiar setup.
  • Our truck tracker systems include cellular and pure satellite. We’ll even mix and match technologies for an alternative solution that best fits your needs.

Reliable GPS Tracking for Trucks

Eelink GPS truck tracking systems are easy to set up and easy to use. They arrive tested, certified and activated, so that you can start tracking your vehicles immediately! Count on our team to help match your business with the right tracking solution, and to provide the real support you need should a problem arise. Give us a call, and we can discuss how vehicle tracking works and which options work best for you.

Call us today for bus and truck monitoring systems that help manage your business.

Environment for use



1,Limited working temperature:-20°C~80°C
2,Storage temperature:-45°C~90°C
3,Humidity:<95%
4,Atmospheric pressure:86kPa~106kPa
5,Make sure the terminal is installed in rainproof
and snow-proof places.

6.200MAh battery



Basic Specifications:
Voltage: 12VDC/24VDC
Standby : Current <3mA
Work current : <30mA
GPS positioning accuracy : 15m
GSM positioning accuracy : 100m
GPS Frequency : 1575MHz
GSM Frequency : 850/900/1800/1900MHz
Hot/warm/cold start time : <3s,<15s,<60s
Dimensions (mm) L*W*H : 79.5X38.5X10.5
Weight : 45 g



Product Features
1.Supports quad bands, i.e. 850/900/1800/1900MHz, universal in the world.
2.Wide Input Voltage:6-36V DC.
3.Supports single positioning and feedbacks position via GPRS at setting times.
4.Supports vehicle positioning and tracking.
5.Supports ACC status checking and vehicle status notifying.
6.Use relay to remote control the vehicle..
7.Use SOS button for SOS call.
8.Use external MIC to monitor remotely



 Main function

Brand Eelink
Model TK116
Quantity 1 piece(s)
Color Black
Material ABS
Network GSM
Band 85090018001900 MHz
SIM Card Qty. one SIM
Emergency Phone Number Qty. 3
Tracking Information Method Monitoring and controlling platform
Power Supply DC 6~36V
GPS Chip SIRF
GPS Sensitivity -163 dB
GPS Channel 20
Position Accuracy 10 m
Altitude Limit 18000 m
Hot Start 3 seconds
Warm Start 15 seconds
Cold Start 60 seconds
SOS Yes
Geo-fence Yes
Vibrating Alerts Yes
Remote Monitoring Yes
Engine Cut Off Yes
Realtime Monitoring Yes
Track Playback Yes
ACC Anti-Theft Yes
Overspeed Alerts Yes
Low Battery Alerts Yes
GPS Blind Area Alarm Yes
Voice Call No
Waterproof Function Yes
Waterproof Rate Daily user water resistant
Working Temperature -35~75'C
Working Humidity 5%~95%
Manufacturer's Warranty 12 Months excluding physical damages (see specifications for terms and details)
Certification CE
Packing List 1 x GPS (5cm)
  1 x Power cable (100cm)
  1 x Microphone (150cm)
  1 x SOS button
  1 x English user manual
  1 x Chinese / English instruction manual





GPS Truck tracking solutions



 Truck tracking Device, Track your truck via VT06







Detail picture

 Truck tracking Device, Track your truck via VT06Truck tracking Device, Track your truck via VT06Truck tracking Device, Track your truck via VT06










GPS TRACKING SYSTEM



 Truck tracking Device, Track your truck via VT06Truck tracking Device, Track your truck via VT06







PACKAGE

Packing List 1 x GPS (5cm)
  1 x Power cable (100cm)
  1 x Microphone (150cm)
  1 x SOS button
  1 x English user manual
  1 x Chinese / English instruction manual





 Truck tracking Device, Track your truck via VT06



  ACCESSORIES



Truck tracking Device, Track your truck via VT06



Truck tracking Device, Track your truck via VT06
