Specifications
1speed and location tracking2.in real time demand
3.track using vai PC or mobile device
4.getting text or email alerts
Real-time GPS tracking allows you to know for sure where your vehicles, assets and family members are, up to the minute. From fleet GPS tracking to personal GPS tracking devices, these live tracking tools can be as small a USB flash drive, perfect for covert car tracking or dropping in a backpack. Real-time GPS tracking devices can also be hardwired to a car's power source for unlimited battery life. A car tracker for parentscan allow parents to know for sure that new teen drivers are driving responsibly. View your live tracking results from any computer or smartphone through Eelink Security's exclusive GPS platform. If you're looking for after-the-fact location information, Eelink offers a variety of GPS loggers that will give you the information you need with no monthly GPS fees.
Through Eelink Security's exclusive GPS monitoring platform, you're able to take full control of your real-time GPS tracking device. Set up geofence alerts to receive text or email notifications the moment the trackers exits or enters a certain area; perfect for monitoring a company vehicle if it goes off course. You'll also receive speed alerts notifying you the moment the real-time GPS tracker exceeds a certain speed. Ensure that your son isn't abusing your trust by speeding in your car. No matter what real-time GPS tracking device you choose, you'll get all of these features and more, accessible directly on your smartphone or PC.
APPLICATIONS
Car rental solution
Taxi management solution
Vehicle tracking solution
Trucking and logistics solution
Secure transportation solution
Service oriented transporter solution
Operation centric solution
School bus management solution
Employee commuting solution
Police and public safety solution
Environment for use
1,Limited working temperature:-20°C~80°C
2,Storage temperature:-45°C~90°C
3,Humidity:<95%
4,Atmospheric pressure:86kPa~106kPa
5,Make sure the terminal is installed in rainproof
and snow-proof places.
6.200MAh battery
Basic Specifications:
Voltage: 12VDC/24VDC
Standby : Current <3mA
Work current : <30mA
GPS positioning accuracy : 15m
GSM positioning accuracy : 100m
GPS Frequency : 1575MHz
GSM Frequency : 850/900/1800/1900MHz
Hot/warm/cold start time : <3s,<15s,<60s
Dimensions (mm) L*W*H : 79.5X38.5X10.5
Weight : 45 g
Product Features
1.Supports quad bands, i.e. 850/900/1800/1900MHz, universal in the world.
2.Wide Input Voltage:6-36V DC.
3.Supports single positioning and feedbacks position via GPRS at setting times.
4.Supports vehicle positioning and tracking.
5.Supports ACC status checking and vehicle status notifying.
6.Use relay to remote control the vehicle..
7.Use SOS button for SOS call.
8.Use external MIC to monitor remotely
Main function
| Brand | Eelink |
| Model | TK116 |
| Quantity | 1 piece(s) |
| Color | Black |
| Material | ABS |
| Network | GSM |
| Band | 85090018001900 MHz |
| SIM Card Qty. | one SIM |
| Emergency Phone Number Qty. | 3 |
| Tracking Information Method | Monitoring and controlling platform |
| Power Supply | DC 6~36V |
| GPS Chip | SIRF |
| GPS Sensitivity | -163 dB |
| GPS Channel | 20 |
| Position Accuracy | 10 m |
| Altitude Limit | 18000 m |
| Hot Start | 3 seconds |
| Warm Start | 15 seconds |
| Cold Start | 60 seconds |
| SOS | Yes |
| Geo-fence | Yes |
| Vibrating Alerts | Yes |
| Remote Monitoring | Yes |
| Engine Cut Off | Yes |
| Realtime Monitoring | Yes |
| Track Playback | Yes |
| ACC Anti-Theft | Yes |
| Overspeed Alerts | Yes |
| Low Battery Alerts | Yes |
| GPS Blind Area Alarm | Yes |
| Voice Call | No |
| Waterproof Function | Yes |
| Waterproof Rate | Daily user water resistant |
| Working Temperature | -35~75'C |
| Working Humidity | 5%~95% |
| Manufacturer's Warranty | 12 Months excluding physical damages (see specifications for terms and details) |
| Certification | CE |
| Packing List | 1 x GPS (5cm) |
| 1 x Power cable (100cm) | |
| 1 x Microphone (150cm) | |
| 1 x SOS button | |
| 1 x English user manual | |
| 1 x Chinese / English instruction manual |
GPS Car tracking solutions
Detail picture
GPS TRACKING SYSTEM
PACKAGE
| Packing List | 1 x GPS (5cm) |
| 1 x Power cable (100cm) | |
| 1 x Microphone (150cm) | |
| 1 x SOS button | |
| 1 x English user manual | |
| 1 x Chinese / English instruction manual |
ACCESSORIES
Records GPS locations of the trackerPut on a vehicle, let it drive, and use a computer to see everywhere it wasVery small, portable designBuilt-in magnet to place underneath a vehicleRuns on 2xAAA batteriesNo monthly service charges
