chinese vertical milling machine BM7130
The milling head moves upwards and downwards along the column, the worktable can carry heavy load. The miller can make high precision which is suitable to process high-duty cutting.
Standard Accessories
Draw bar
Tool box
Tools
Oil collecting plate
Auto. Lubicate pump
Coolant pump
Table guard
Working lamp
Special accessories Digital readout
Power feed
Collets chuck
Clamping kits
Machine vise
Inverter milling head
Variable speed milling head
Air draw bar
chinese vertical milling machine BM7130
chinese vertical milling machine BM7130
model |
BM7036 |
BM7125 |
BM7125 |
BM7130 |
BM7130 |
||
Table size |
360 x 1250 |
254x 1270 |
254 x 1370 |
305 x 1370 |
305 x 1500 |
||
Table longitudinal travel |
1000 |
760 |
860 |
880 |
1000 |
||
Table cross travel |
420 |
535 |
535 |
510 |
510 |
||
Milling head vertical travel |
450 |
405 |
405 |
405 |
405 |
||
Distance from spindle to table |
120-580 |
150 - 600 |
150 - 600 |
150 - 600 |
150 - 600 |
||
Milling head |
Motor power |
5HP |
3HP |
3HP |
5HP |
5HP |
|
Spindle taper |
ISO40 |
R8 |
R8 |
ISO40 |
ISO40 |
||
Quill travel |
150 |
127 |
127 |
127 |
127 |
||
Spindle speed |
Standard |
10steps 80-5440 50HZ: 65-4500 60HZ: 80-5440/16steps |
|||||
Optional: Variable |
65-4200 |
60-3750 |
|||||
Quill power feed |
0.04/0.08/0.15mm/rev |
||||||
Package size |
One macine / 1 package |
222 x 114 x 234cm |
180 x 150 x 240cm |
185 x 150 x 240cm |
|||
Two machine / 1 Package |
220 x 150 x 240cm |
225 x 150 x 240cm |
|||||
G.W. |
One machine |
1820 |
1900 |
1900 |
2000 |
2050 |
|
Two machine |
2000 |
3900 |
3900 |
4000 |
4100 |
||
Our service:
1.All of our goods will pass QUALITY INSPECTIONS before shipment.Best after sale service, customer can follow their order sit uation any time, no matter on product line, warehouse or shipment.
2.More than 10 years experience in exporting to make your order more smooth.Less than one container loading is accepted.
On time delivery, in general 30 days. Multimode payment:T/T,L/C.
3.Special dimensions available according to request.
4.We have many certificates of our Products.
5.Accessories replacement if our product itself has quality problems during one year after receiving.
