ALMACO best sale and advanced China vertial cylinder honing machine 3M9814A
- 30 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Double Platform Stainless Steel Kitchen Equipment Polishing Machine
- Photovoltaic solar panels recycling plant
- Solar panel recycling machine with high efficiency
- Micro wire mesh weaving machine from LANYING wire mesh weaving machine
- LANYING woven wire mesh machines - stainless steel wire mesh weaving machines
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | ALMACO | Model Number: | 3M9814A |
Product Description
Vertical cylinder honing machine:
The vertical honing is used for honing holes of cylinder body and sleeve for engines & other accurate hole.
Vertical cylinder honing machine 3M9814A:
Vertical cylinder honing machine 3M9814A:
Model | Unit | 3M9814A | 3MQ9814 | MJ4214B | 3M9816 | 3MQ9817 | 2M2217 | M4215/1 | MJ4220A |
Dia of hole honed | mm | Φ40-140 | Φ40-140 | Φ40-140 | Φ45-160 | Φ35-170 | Φ32-170 | Φ30-150 | Φ32-200 |
Max depth of hole honed | mm | 320 | 320 | 370 | 320 | 320 | 320 | 400 | 500 |
spindle speed | rpm | 128,240 | 15,250 | 125,215 | 125,250 | 120,160,225,290 | 115,160,225,320 | 140,200,280 | 40-300 |
Stroke | spm | 35,44,65 | |||||||
Longitudinal travel of honing head | mm | 720 | 340 | 350 | |||||
spindle lifting/lowering speed | m/min | 0-10 | 0-14 | 3-10 | 0-10 | 0-30 | 2-18 | 3-18 | 4-20 |
Table swivel | ° | 0,30,45 | |||||||
Table longitudinal traverse | mm | 750 | 800 | 800 | |||||
Max manual table lifting | mm | 180 | 400 | ||||||
Max spindle reliprocating travel | mm | 300 | 370 | 450 | |||||
POwer of honing head motor | KW | 0.75 | 0.75 | 1.1 | 1.5 | 2.2 | |||
Power of cooling pump motor | KW | 1.1 | 0.125 | 0.125 | |||||
Power of hydraulic pump | KW | 2.2 | |||||||
Inside cavity dimensions | mm | 350*900 | 1400*870 | 1000*400 | 1100*480 | 1500*600 | |||
Overall dimensions(L*W*H) | cm | 144*96*166 | 129*88*202 | 160*93*187 | 124*85*230 | 164*167*192 | 190*121*199 | 132*168*267 | 155*142*223 |
Net weight | kg | 510 | 650 | 750 | 940 | 1000 | 2000 | 2100 | 2500 |
Our services:
1,Your inquiry will be replied in 24 huors.
2.Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 6
years.And there is more industry technology experience for 20 years with our manufactures
3.To offer free spare parts and service within one year of warranty
4.Technology Support Provide operation video for training
5.Professional after-sales service team
6.Give reasonable offers with the best quality
Our advantage:
1,More then 20 years experience for indusry product
2,All modles with CE,TUV,SGS,ISO9001/9002 or other authority approved
3,Professional service and technology
4,Excellent reputation all over the world
5,Final exported producuts would pass strict test by international authority BIVAC
6, There is more exporting experience for 20years with our owned manufacture/company
Welcome to Almaco Machine Tool Co., Ltd
our company as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation,specializes in import & export of brand-new industrial machinery & tools.Our mechanical products with ISO9001 or CE certificate cover more than 80 kinds including lathe ,milling machine,grinding machine,power press,guillotine shearer,hydraulic press brake,CNC Machine and so on,which have been exported to 40 or more countries & areas.
We are looking forward to bulding sincere and long-term business relationship with you
