DX5 High Resolution Flex Banner Printing Machine

Model

FT-1800

Print Head

Drop-on-demand Micro Piezo Inkjet Technology,  DX5 print head

Print head nozzle

(180nozeel*8lines) per one head

Ink

Water base ink/Eco solvent ink

Color Mode

Dual CMYK

Print head Height adjustment

1.5mm & 2.5mm adjustable

Head Cleaning

Automatic purging, sucking, wiping

Ink supply

Refillable cartridge

Media width

1.60m ,1.80m

Print width

1.52m ,1.70m,1.80m.

Print Margin

5mm min.

Roll media weight

20kg MAX

Printing material with eco solvent ink

Vinyl, flex banner, etc

Printing material with water base ink

photo paper, pp paper, light box film, etc

Resolution and printing speed

360*1080( 6 pass)                 10.5sqm/h

720*360( 4 pass)                  15sqm/h

720*720( 8 pass)                   8sqm/h

1440*720( 8 pass)                  3.5sqm/h

1440*1440( 16 pass)                2sqm/h

Heating system

Front heating and Back heating, two stage

Optional struction

Hot dry( hot fans)

Automatic feed-in and take-up media system

Inter face

USB2.0/USBHI

RAM

128M

Power

AC110-120V, AC220-240V( adaptive), 50/60HZ±1HZ

Power Consumption

Printing mode:100W

Standby mode:40W

Noise Level

≤50DB

Environment

Temperature 20-32 Humidty:40%-60%(non-dondensing)

Dimension

2.65m*0.92m*0.63m( with package)

Weight

210kg
