DX5 Print Head Indoor and Outdoor Flex Printing Machine

Name: DX5 Print Head Indoor and Outdoor Flex Printing Machine
Brand: SMARTCOLOR
SKU: 115126437

US$ 3,600 - 3,900 MOQ: 1 Set

Key Specifications

Condition:

New

Plate Type:

Screen Printer

Place of Origin:

Jiangsu, China

Nanjing Fortune-Lit Digital Technology Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Screen Printer

Place of Origin Jiangsu, China

Brand Name SMARTCOLOR

Model Number FT-1560

Usage Paper Printer

Automatic Grade Automatic

Voltage 110V/220V

Gross Power 50/60HZ

Weight 250KGS

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Speification :

----- One DX5 print head ensures higher speed and precise inkjet.

----- Double 4 colors and 8 color give more color output.

----- High-quality print model delivers consistent, reliable results.

----- Maximum 1440dpix1440dpi.

----- Front heating system help drying faster

Model	FT-1560
Print Head	Drop-on-demand Micro Piezo Inkjet Technology, DX5 print head
Print head nozzle	(180nozeel*8lines) per one head
Ink	Water base ink
Color Mode	Dual CMYK
Print head Height adjustment	1.5mm & 2.5mm adjustable
Head Cleaning	Automatic purging, sucking, wiping
Ink supply	Refillable cartridge
Media width	1520mm max
Print Margin	5mm min.
Roll media weight	20kg MAX
Printing material with water base ink	photo paper, pp paper, light box film, etc
Resolution and printing speed	3601080( 6 pass) 12sqm/h 720360( 4 pass) 15sqm/h 720720( 8 pass) 8sqm/h 1440720( 8 pass) 4sqm/h 1440*1440( 16 pass) 2sqm/h
Heating system	Front heating and Back heating, two stage
Optional struction	Hot dry( hot fans)
	Automatic feed-in and take-up media system
Inter face	USB2.0/USBHI
RAM	128M
Power	AC110-120V, AC220-240V( adaptive), 50/60HZ±1HZ
Power Consumption	Printing mode:100W
	Standby mode:40W
Noise Level	≤50DB
Environment	Temperature 20-32 Humidty:40%-60%(non-dondensing)
Dimension	2.4m0.75m1.25m( with package)
Weight	150kg
