Help Center50W Power Led and Driver
Related Products
Specifications
50W Power led and driver1)AC INPUT POWER .
2)HIGH EFFICIENCY AND LOWOPERATION TEMPERATURE
3)COMPACT SIZE LIGHT WEIGHT
4)c
|
|
Product Electric Parameters | ||||
Input specification |
Input voltage |
AC90V---264V |
||
Input frequency |
47-63Hz |
|||
Input surge |
20A@120VAC 40A@230VAC |
|||
Output specification |
Output voltage can be adjusted |
±10% |
||
Start-up time |
≤1S(input230V,Io=100%) |
|||
keep time |
≥20mS (input230V,Io=100%) |
|||
Voltage regulation |
(Full load) ≤0.5% |
|||
Protection function |
Overload protection |
105% - 150% rated power, automatic recovery |
||
Over-voltage protection |
105% - 150% of the rated voltage |
|||
Insulation intensity |
Input---output |
1500VAC/1min |
||
Input---ground |
1500VAC/1min |
|||
Input---ground |
500VAC/1min |
|||
Safety standards |
According with GB4943, UL60950-1,EN60950-1 standards. |
|||
E M C standards |
According with GB9254, EN55022 class A ?EN61347-2-13:2008 standards |
|||
|
Environmental |
working temperature |
- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost) |
||
Storage temperature |
–40°C~85°C/10%~95%RH |
|||
height above sea level |
≤2000M |
|||
Structure |
Size(mm) |
110(L)*78(W)*35(H) |
||
Cooling method |
Cooling method |
Natural cooling air convection |
||
Weight |
0.2KG/PCS |
|||
Product Type Table | ||||
Product model |
output specification |
ripple, noise |
efficiency |
|
S-50-3.3 |
3.3V |
10A |
50mV |
66% |
S-50-5 |
5V |
10A |
50mV |
76% |
S-50-9 |
9V |
5.5A |
70mV |
78% |
S-50-12 |
12V |
4.2A |
100mV |
80% |
S-50-15 |
15V |
3.3A |
100mV |
80% |
S-50-24 |
24V |
2A |
100mV |
80% |
S-50-28 |
28V |
1.8A |
100mV |
80% |
S-50-36 |
36V |
1.4A |
120mV |
80% |
S-50-48 |
48V |
1A |
240mV |
82% |
