12v dc Transformer

Name: 12v dc Transformer
Brand: zoyea
SKU: 115105337
Availability: InStock

US$ 6.8 - 6.83 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

zoyea

Model Number:

S-120w

Shenzhen Zoyea LED Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name zoyea

Model Number S-120w

Output Power Other, 100W

Output Type Single

Input Voltage Other, 90~264V

Output Voltage 12v

Output Frequency 47-63HZ

Output Current 10A

Specifications

12v dc transformer
1.100% load test.
2.CE&ROHS
3.Efficiency 85%
4.Quality assurance year

12v dc transformer

Product Electric Parameters
Input specification	Input voltage		AC90V---264V
	Input frequency		47-63Hz
	Input surge		20A@120VAC 40A@230VAC
Output specification	Output voltage can be adjusted		±10%
	Start-up time		≤1S(input230V,Io=100%)
	keep time		≥20mS (input230V,Io=100%)
	Voltage regulation		(Full load) ≤0.5%
Protection function	Overload protection		105% - 150% rated power, automatic recovery
	Over-voltage protection		105% - 150% of the rated voltage
Insulation intensity	Input---output		1500VAC/1min
	Input---ground		1500VAC/1min
	Input---ground		500VAC/1min
Safety standards	According with GB4943, UL60950-1,EN60950-1 standards.
E M C standards	GB9254, EN55022 class A EN61347-2-13:2008 According with GB9254, EN55022 class A ?EN61347-2-13:2008 standards
Environmental	working temperature		- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
	Storage temperature		- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
	height above sea level		≤2000M
Structure	Size(mm)		199(L)98(W)38(H)
Cooling method	Cooling method		Natural cooling air convection
Weight	0.5KG/PCS
Product Type Table
Product model	output specification			ripple, noise	efficiency
S-100-3.3	3.3V	20A		50mV	66%
S-100-5	5V	20A		50mV	76%
S-100-9	9V	11A		70mV	78%
S-100-12	12V	8.5A		100mV	80%
S-100-15	15V	7A		100mV	80%
S-100-24	24V	4.5A		100mV	80%
S-100-28	28V	3.6A		100mV	80%
S-100-36	36V	2.8A		120mV	80%
S-100-48	48V	2.3A		240mV	82%
