IP67 50w 1.2A led transformer for led light
More Products:
20w 0.3A led driver 20w 0.6A led transformer 120w 24v standard led driver
20w 12v led power supply 20w ip67 led driver
Specification
| Model | FS-50 | |||
| Output | Dc Voltage | 18-34V | ||
| Rated Current | 1.2A | |||
| Voltage Range | 18~34V | |||
| Rated Power | 20 | |||
| Ripple&Noise(Max) | 150mV | |||
| Current Tolerance | ±4% | |||
| Setup,Rise Time | 100ms/220VAC | |||
| Hold Up Time(Typ.) | 80ms/220VAC | |||
| Input | Voltage Range | 85~277VAC | ||
| Frequency Range | 47~60Hz | |||
| Power Factor(Typ) | PF>0.95 | |||
| Efficiency(Typ) | 89% | |||
| Protection | Short Circuit | Protection type,recovers automatically after fault conditions is removed | ||
| Overlaod | Overload protection@145~160%above peak rating | |||
| Over Temperature | protection typer, shut down o/p voltage.re-power on to recover | |||
| Environment | Working Temp | -30~ +60°C(Refer to output load derating curve) | ||
| Working Humidity | 20~90%RH no-condensing (Waterproof) | |||
| Storage Temp Humidity | -40~ +80°C,10~90%RH | |||
| Safety&Emc | Safety Standards | CE Mark(LVD),IP67 | ||
| Withstand Voltage | I/P-O/P;.5KVAC IP-GND;.5KVAC | |||
| Emc Test Standards | EN 550152006; EN 615471995+A12000 ;EN 61000-3-22006; EN61000-3-21995+A22005 EN 61347-12008 EN 61347-2-132006 |
|||
| Connect the line request | Input:H03VV-F 3G*0.75mm Brown&blue&kelly VDE(200mm) Output:H03VV-F 2*0.75mm Black & Red VDE(300mm*2) | |||
| NOTE | 1.All parameters NOT specially mentioned are measured at 220VAC input,rated laod and 25°C of ambient temperature. | |||
| 2.Ripple&noise are measured at 20MHz of bandwidth by using a12''twisted pair-wire terminated with a 0.1uf&10uf parallel capacitor. | ||||
| 3.Tolerance:includes set up tolerance,line regulation and load regulation. | ||||
| Others | Dimension | 112*37*29(mm)(L*W*H) | ||
| Carton Quantity | 20PCS/Carton | |||
| Carton Size | 80*25*21mm | |||
| Weight | 0.02kg/pcs | |||
More details:
Q1: Are you manufacturer or trading company?
A1: We are the real manufacturer which focus on power supply & Led driver,but not the trading factory for different kind of product.
Q2: What is the Warranty for your product?
A2: We are the only power supply manufacture can provide LIFETIME WARRANTY,the failed items can be repalced with the new order no matter when you buty them,so you don't need to worry about the quality problem if cooperate with us.
Q3: What kind of payment term do you accpet?
A3: T/T,L/C,Paypal,Western Union,MoneyGram,Escrow,O/A.
Q4:: What is your MOQ?
A4:The MOQ can be only 1PCS.
Q5: What's your Lead time?
A5: The delivery time is 1~25 days which depend on detail item and quantity.
Q6: Do you accept OEM?
A6: Yes.
Q7: Can we be your distributor?
A7: Yes,if your annuals sales much more than our other customers in your market that you can be our distributor
