220v ac to 12v dc Rgb Led Light Driver

Name: 220v ac to 12v dc Rgb Led Light Driver
Brand: zoyea
SKU: 115098981
Availability: InStock

Shenzhen Zoyea LED Technology Co., Ltd.

US$ 6.5 - 9 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

zoyea

Model Number:

FSV-12060

Payment & Shipping

Payment Methods:

Port of Shipment:

shengzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name zoyea

Model Number FSV-12060

Output Power Other, 60w

Output Type Single

Input Voltage Other, 90-264v

Output Voltage 12V+_0.5

Output Frequency 47~60Hz

Output Current 5A

Specifications

1. 220v ac to 12v dc rgb led light driver
2. IP67
3. 100% load test
4. Two years warranty
5. CE&ROHS

Product Description

Features:

1. Constant Voltage mode power supply

2. Universal AC input(95-265V)

3. Fully encapsulated with IP67 level

4.Withstand 300VAC surge input for 5seconds

5. Protections:Short circuit/Over load/Over current

6. Cooling by free air convection

7. 100% full load burn-in test

8. High Reliability

9. Meet RoHS/CE

10. 2 year warranty

11. Waterproof, meet IP67

specifications :

Product Electric Parameters
Input specification	Input voltage		AC90V---264V
	Input frequency		47-63Hz
	Input surge		20A@120VAC 40A@230VAC
Output specification	Start-up time		leq1S (230V Input,Io=100%)
	keep time		more than or equal to 20mS (230V Input,Io=100%)
	Voltage regulation		(full)leq0.5%
Protection function	Overload protection		105% - 150% rated power, automatic recovery
	Over-voltage protection		105% - 150% of the rated voltage
Insulation intensity	Input---output		1500VAC/1min
	Input--ground		1500VAC/1min
	Output---ground		500VAC/1min
Safety standards	According with GB4943, UL60950-1,EN60950-1 standards.
E M C standards	According with GB9254, EN55022 class A EN61347-2-13:2008 standards
Environmental	working temperature		- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
	Storage temperature		- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
	height above sea level		leq2000M
Structure	Size (mm)		150(L)52(W)*33(H)
Cooling method	Cooling method		Natural cooling air convection
Weight	0.505KG/PCS
Product Type Table
Product model	output specification			ripple, noise	efficiency
F60-12	12V	5A		120mV	85%
F-60-24	24V	2.5A		240mV	85%
