Specifications
Solid carbide plate for punching die;optimum properties;
expert technology;
10 years of experience
ISO 9001 certified
We produce Solid carbide plate for punching die in different sizes and grades.
Customers' designs are also welcomed.
Grade |
Density g/cm3 |
TRS N/mm2 |
Hardness(HRA) |
Application recommended |
YF10.1 |
14.80—15.15 |
≥1880 |
≥91.0 |
Suitable for drawing dies to draw small diameter ferrous wire and non-ferrous metal wire a high speed |
YF10.2 |
14.30—14.65 |
≥2430 |
≥91.8 |
Suitable for strips to make wood-working tools |
YL80 |
13.75—14.05 |
≥3200 |
≥89.5 |
Suitable for plates to make die blanks |
YL80.1 |
14.70—14.90 |
≥2020 |
≥89.5 |
High abrasion resistance, used in powder metallurgy mould etc. |
YL80.2 |
14.00—14.20 |
≥2900 |
≥86.5 |
Suitable for making small watch parts, punching dies of instrument, roll, cut the trigger. |
YL80.3 |
13.50—13.80 |
≥2540 |
≥85.0 |
Suitable for producing punching plate under high stress. |
YL90 |
13.50—13.70 |
≥2500 |
≥82.5 |
With high strength and toughness, suitable for making large size reducing die, better than YG20C. |
YL90.1 |
13.90—14.10 |
≥2340 |
≥84.5 |
Suitable for die blanks for reducing diameter with large dimension and dies blanks assembled of six pieces |
YL90.2 |
13.70—13.90 |
≥2400 |
≥83.0 |
Suitable for die blanks for reducing diameter with middle dimension |
YL90.4 |
13.20—13.40 |
≥2600 |
≥82.0 |
High strength and toughness, used to cold heading mould, cold impacting mould and cold press mould with high pressing |
YL90.5 |
13.00—13.20 |
≥2760 |
≥81.0 |
Good impact resistance, fatigue resistan,used for high loading punching die |
YL90L |
13.20—13.40 |
≥2550 |
≥81.5 |
Used for general cold screw scissors die and cutting shear blade tips |
YG6A |
14.80—15.10 |
≥1580 |
≥91.5 |
Suitable for semi-finishing of cast, nonferrous metal and low-alloy steel |
YG6X |
14.70—15.10 |
≥1600 |
≥91.0 |
Suitable for drawing dies to draw steel wire, on-ferrous wire and rods with small diameter at a high speed |
YG6 |
14.70—15.05 |
≥1670 |
≥89.5 |
Suitable for drawing dies to draw steel wire, on-ferrous wire under a diameter of 20mm and tubes under a diameter of 10mm |
YG8 |
14.60—14.8 |
≥1840 |
≥89 |
Suitable for drawing dies to draw steel wire, on-ferrous wire and alloy rods, tubes, also for making wear parts, tools(such as muzzles, grinders, drills ect.) |
YG15 |
13.90—14.20 |
≥2700 |
≥86.5 |
Suitable for drawing dies to draw steel rods and tubes at a high compression ratio, also for heading dies, drills etc. |
YG20 |
13.40—13.70 |
≥2480 |
≥84.5 |
Suitable for punching and heading dies |
For more information on Solid carbide plate for punching die, please contact me directly.
