Help CenterPackmate Doypack Zipper Bags Packing Machine
Related Products
Specifications
Packing Machine1.Capacity(bags/min):<40
2.Film Width(mm):<700
3.Power supply:AC220,50/60HZ,1-phase
4.Weight:30
Description
·Highlights the product with great effect and real cost saving in comparison with the traditional premade bag packaging machine and carton packers.
·Produce stand -up doypack, standard pillow bags and flat bottom bags, 3-side and 4-side sealling possible .
·Former changes take only a few minutes .
·Automatics PLC program set-up and interactive touch screen panel.
·Dual vacuum adsorption film pulling belts controlled by servo motor, film draw with tension control.
·Zipper application optional possible.
Application:
The automatic vertical form fill seal packaging machine pack almost all granule, powder and liquid material ,such as: sweets, puff snack food, potato chips, crispy rice, jelly, candy,, dumpling, small cookie, milk powder, liquid and non-food, etc
Machines parts and system accessaries :
Material feeding funnel
Film roll unwinding system with motorize control
Date printing device
Encoder bag length control and eye-mark tracking
Bag forming, filling and sealing
Bag cutting and finish bag exit
Key Features of VFFS:
Servo motor driven pull belts
PLC based, 7 inch touch screen parameter adjustment
Pneumatically operated horizontal sealing jaws
PID digital temperature control
Motorized film unwinding system
Encoder bag length control
Photo cell for bag eye-mark registration
One forming assembly for fast changeover bag size, no tools need.
Safety guard with safety switch
Air regulator, filter and lubricator
Automatic pneumatic air purge
Technical data :
Model |
VFFS 700W/FZ |
Capacity(bags/min) |
≤40 |
Film Width(mm) |
≤700 |
Power supply |
AC220,50/60HZ,1-phase |
Weight |
30 |
100 |
150 |
500 |
1000 |
Width(mm) |
80 |
120 |
160 |
190 |
240 |
Length(mm) |
130 |
200 |
230 |
265 |
335 |
Bottom Gusset(mm) |
40 |
60 |
70 |
90 |
100 |
Bag style :
PACKMATE HIGH QUALITY MACHINE PHOTOS:
