YZS Vibrating Screen:

YZS circular vibrating screen is a new screening equipment for the circular vibration, which is specifically designed for screening material stone in the quarry, and also used for classification in the departments of coal selecting, mineral processing, building materials, electricity and chemical products. The output of Our vibrating screen conforms to the national standard and reachs the highest level at home and abroad. Also it wins good praise from customers. The Vibrating Screen (Vibratory Screen) is of many layers and high efficiency. The vibratory screen adopts the barrel type of eccentric shaft vibration exciter and eccentric block to adjust the swing.

Main structure of circular vibrating screen:

YZS series circular vibrating screen mainly consists of the eccentric shaker, sieve boxes, motors, bases and supporting equipment.

Working principle of circular vibrating screen:

The eccentric vibrator high-speedly rotates by the motor through V-belts,the rotating eccentric block produces large centrifugal force to bring sieve boxes circle moving with certain amplitude. Under the impluse of the sieve box, the materials on the leaning screens produce a continuous throwing motion; In the contacting process of the materials and screen surface, particles smaller than sieve pass through the screen and classification is realized.

Circular vibrating screen has the following features:

1. new structure ,advance technical data, high processing capacity and high screening efficiency

2.Circular Vibrating Screen adopts tube-type eccentric shaft vibration exciter and partial block of conditioning amplitude; easy operation and maintenance.

3. Circular Vibrating Screen with spring steel woven mesh or perforated metal sieve, long life, not easily plug holes.

4.Circular Vibrating Screen with rubber isolation springs, long life, low noise, and pass through resonance region easily.

Usage and maintenance of circular vibrating screen:

Vibrating screen should start wihtout the materials on the screen surface, and try to avoid start the mahcine with materials, screen machine should make sure to run smoothly before feeding material. Before halt, feeding materials should be first stopped and all the materials are discharged. In the working process, the operating situation must be checked regularly, once operate improperly or have abnormal sound, the machine must be stopped for check.The reasons must be found and the faults must be removed.

Technical parameter:

Note: This is specification is just reference, any changes are subject to the products.

Notes during using:

1.Please read operation manual carefully before use.the machine may only be operated by fully authorized,trained personnel.

2.Make sure that the machine starts without any load. The machine can only be started after.All people are away from it.and wear safty hemlet and pay attention to flying stones,please atand outside the safe distance.

3.when machine runing All adjustment,clearance or check-up is strictly prohibited keep away from any running part. Overlaaded operation is strictly prohibited.

4.Lubriate and maintain the machine timelyBefore halt for check,feeder should be first stopped feeding and make sure the stones are all out of the machine silo.

Our Services

Pre-sale:
(1) According to customer's special requirements, design and manufacture of products.
(2) the company free of charge to the user onsite engineering and technical personnel planning site for the user to design the  best processes and programs.
Sale:
(1) product acceptance.
(2) to help customers develop construction programs.
After-sale:
(1) free to assign a dedicated service personnel, arrived at the scene and guide customers installation.
(2) equipment installation.
(3)complete sets of equipment installed.

Packaging & Shipping

Our products are usually packed by plywood case,wooden case,nylon coth, etc. And we will change packing ways by the real situation. The goods will be delivred from Qingdao port and we will take buyers requirements into consider,too.

Our certificates

Cooperation with foreign customers

Order Online:

If you're interested in the product, please submit your requirements and contacts and then we will contact you in two days. We promise that all your information won't be leaked to anyone.
